BLUM ZX-Speed User Manual

Mountingandcommissioning
©byBlum‐Novotest
13
322000010S|V1B|07/2017
4.2 Adjustmentofprobe
4.2.1 Cable(outgoing)onside
Fig.4‐6
Adjustmentpossibilitywithroundedwasher,inordertocompensatepossibleangleerrorsof
theinstallation.
1. Inserttheroundedwasherintotherecessofthebottomofthehousing.
2. Adjusttheprobebyreciprocallooseningandtighteningofthediagonallyoppositehe xagon
screws(M
d
= 1.1 Nm).
1°
1°
12
16
0,5
(12) Roundedwasher
(16) DINENISO4762‐M3x14(DIN912)
