BLUM ZX-Speed User Manual

Systemoverview
322000010S|V1B|07/2017
6
©byBlum‐Novotest
3. Systemoverview
3.1 Description
Fig.3‐1
3.2 Displayelements
Tab.3‐1
14 131516
11
12
7
1
8
9
(1) Measuringsurface
(7) Probecontact
(8) Adapterwithpredeterminedbreak‐
ingpoint
(9) Chipprotection
(11) LED
(12) Roundedwasher
(13) Cable
(14) Spiralhose
(15) Hosenut
(16) DINENISO4762M3x14(DIN912)
Colour LED(11)
Standby
Probeinitialposition
Probedeflected
