BLUM ZX-Speed User Manual

Systemoverview
322000010S|V1B|07/2017
8
©byBlum‐Novotest
3.4 Technicaldata
Tab.3‐2
Protectionclass IP68
PowersupplyU
B
12 ... 30 V DC (stabilized) / 100 mA
Outputs 12 ... 30 V / 50 mA
Approachdirection ±X,±Y,‐Z
Measuringforce
•directionX/Y:
•directionZ:
1.7 N
3N
max.stroke/deflection
•directionX/Y:
•directionZ:
±11°(5.3mm)
6mm
Repeatability 0.4 µm 2
Max.probingspeed 2 m/min
Min.tooldiameter
a
1mm
Mass,incl.cable10m700g
Min.bendingradiuscable
• static
•flexible
26 mm
60 mm
Storagetemperature ‐20 °C ... +70 °C
Oper atingtemperature +5 °C ... +50 °C
a
Dependingontoolgeometryandmaterialaswellasprobingspeed,thetoolmaynotbedamagedbythe
probingforce.
