BLUM ZX-Speed User Manual

Maintenance
©byBlum‐Novotest
21
322000010S|V1B|07/2017
7. Maintenance
•Theprobeneedsminimummaintenanceonly
• Dependingonapplicationconditionslubricatethemeasuringsurfaceoccasionally,e.g.with
multi‐functionoilWD40.
NOTICE
Pollutionanddamagetothemeasuringmechanism
Thebellowsisallowedtobeex changedbyBlum‐Novotestonly!
 Incaseofdamagetothebellows,pleasereturnthemeasuringsystemforrepair.
7.1 Cleaningoftoolsettingprobe
Fig.7‐1
1. Removethechipprotectionandtheprobecontact,seechapter7.2.
2. Cleanallpartswithabrushandcheckthebellowsfordamages.
3. Mountthechipprotectionandtheprobecontact,seechapter7.2.
4. Checktheprobeafterassemblyconcerningparallelism.Theprobema ynotclamponoper‐
ation.
5. Calibratethemea
suringsystembythecalibrationcycle.
