BLUM ZX-Speed User Manual

Mountingandcommissioning
322000010S|V1B|07/2017
16
©byBlum‐Novotest
4.4 Mountingprobecontact
NOTICE
Damagetothemeasuringsystembyimpropermountingpossible.
 Themeasuringelementmaynotbedeflectedduringmounting.
 Whenmountingpleasealwaysusetheprovidedtools.
NOTICE
Damagetothemeasuringsystembyimpropermountingmaybepossible.
 Please ensure the correct usage and position of the  mounting tools when changing the
probecontact,seeFig.4‐9.
Fig.4‐9
Fig.4‐10
55
7
8
9
10
C
D
5
(5) DINENISO4027‐M3(DIN914)
(7) Probecontact
(8) Adapterwithpredeterminedbreak‐
ingpoint
(9) Chipprotection
(10) Predeterminedbreakingpoint
(C) Flatwrench6mm
(D) Allenkey1.5mm
