BMW 2011 R 1200 GS User Manual

If oil level is below MIN mark:
Topping up engine oil ( 98).
If oil level is above MAX mark:
Have oil level corrected by
a specialized workshop,
preferably an authorized BMW
Motorrad retailer.
Topping up engine oil
Make sure ground is level and
firm and park motorcycle.
Wipe area around fill location
clean.
Remove cap 1 of engine oil fill
location with toolkit.
Both too little and too
much engine oil can lead to
engine damage.
Always make sure that the oil
level is correct.
Add engine oil up to specified
level.
Engine oil, quantity for
topping up
max 0.5 quarts (max 0.5 l)
(Difference between MIN
and MAX)
Checking engine oil level
( 97).
Reinstall engine oil fill location
cap.
Brake system
Checking brake operation
Pull handbrake lever.
Pressure point must be clearly
perceptible.
Press footbrake lever.
Pressure point must be clearly
perceptible.
If no clear pressure points are
perceptible:
Incorrect working practices
endanger the reliability of
the brakes.
Have all work on the brake sys-
tem carried out by specialists.
Have the brakes checked by a
certified workshop, preferably
an authorized BMW Motorrad
retailer.
Checking front brake pad
thickness
Make sure ground is level and
firm and park motorcycle.
8
98
z Maintenance

BMW 2011 R 1200 GS Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Power	110 hp (81 kW) at 7, 750 rpm
Compression Ratio	12.0:1
Fuel System	Electronic fuel injection
Final Drive	Shaft drive
ABS	Standard
Front Tire	110/80 R19
Rear Tire	150/70 R17
Dry Weight	203 kg
Weight, ready to ride, fully fueled	229 kg
Engine Type	Air/oil-cooled flat twin ('Boxer')
Torque	120 Nm at 6, 000 rpm
Fuel Type	Unleaded premium
Transmission	6-speed
Frame	Two-section frame consisting of front and rear sections
Front Suspension	Telelever
Rear Suspension	Paralever
Front Brake	Dual disc
Rear Brake	Single disc
Seat Height	850 mm
Wheelbase	1507 mm
Fuel Capacity	20.0 l
