General instructions
The "Maintenance" chapter de-
scribes work involving the check-
ing and replacement of wear
parts that can be performed with
a minimum of effort.
If special tightening torques are
to be taken into account for
assembly, these are listed. An
overview of all required tightening
torques is contained in the
chapter "Technical Data".
Information on additional main-
tenance and repair work is pro-
vided in the Repair Manual for
your motorcycle on DVD, which
you can obtain from your autho-
rized BMW Motorrad retailer.
Special tools and thorough spe-
cialized knowledge are required
to carry out some of the work
described here. If you are in
doubt, consult a certified work-
shop, preferably your authorized
BMW Motorrad retailer.
Onboard toolkit
Standard tool kit
1 Torx wrench T15, T25,
T30
Removing body panels
Removing luggage rack
( 93).
2 Reversible screwdriver with
Phillips and straight blade
Replacing front and
rear turn indicator bulbs
( 114).
3 Open-ended wrench
Wrench size: 14 mm
Adjusting mirror arm
( 53).
4 Open-ended wrench
Wrench size: 8/10 mm
Removing battery
( 122).
5 Tool for oil cap
Topping up engine oil
( 98).
Tool to chassis setting
without Electronic Suspension
Adjustment (ESA)
OE
8
96
z Maintenance

BMW 2011 R 1200 GS Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Power	110 hp (81 kW) at 7, 750 rpm
Compression Ratio	12.0:1
Fuel System	Electronic fuel injection
Final Drive	Shaft drive
ABS	Standard
Front Tire	110/80 R19
Rear Tire	150/70 R17
Dry Weight	203 kg
Weight, ready to ride, fully fueled	229 kg
Engine Type	Air/oil-cooled flat twin ('Boxer')
Torque	120 Nm at 6, 000 rpm
Fuel Type	Unleaded premium
Transmission	6-speed
Frame	Two-section frame consisting of front and rear sections
Front Suspension	Telelever
Rear Suspension	Paralever
Front Brake	Dual disc
Rear Brake	Single disc
Seat Height	850 mm
Wheelbase	1507 mm
Fuel Capacity	20.0 l
