Asynchronously running
engine.
Ensure correct routing of the
throttle control cable.
Make sure that throttle valve
cable is seated in guide 4 of
intake manifold and throttle
valve is resting against stop.
Position tank cover and install
two screws 5.
Press side panel into bracket in
area 3.
Install two screws 2.
Install screw 1.
Press side cover 1 into two
mounts.
Installing driver's seat ( 61).
Jump-starting
The wires leading to the
power socket do not have
a load-capacity rating adequate
for jump-starting the engine. Ex-
cessively high current can lead
to a cable fire or damage to the
motorcycle electronics.
Do not use the onboard socket
to jump-start the engine of the
motorcycle.
8
119
z
Maintenance

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the BMW 2011 R 1200 GS and is the answer not in the manual?

BMW 2011 R 1200 GS Specifications

General IconGeneral
Displacement1170 cc
Bore x Stroke101 mm x 73 mm
Power110 hp (81 kW) at 7, 750 rpm
Compression Ratio12.0:1
Fuel SystemElectronic fuel injection
Final DriveShaft drive
ABSStandard
Front Tire110/80 R19
Rear Tire150/70 R17
Dry Weight203 kg
Weight, ready to ride, fully fueled229 kg
Engine TypeAir/oil-cooled flat twin ('Boxer')
Torque120 Nm at 6, 000 rpm
Fuel TypeUnleaded premium
Transmission6-speed
FrameTwo-section frame consisting of front and rear sections
Front SuspensionTelelever
Rear SuspensionParalever
Front BrakeDual disc
Rear BrakeSingle disc
Seat Height850 mm
Wheelbase1507 mm
Fuel Capacity20.0 l
