BMW 2011 R 1200 GS User Manual

Display
Selecting readings
Switch on ignition.
without onboard computer
OE
without Tire Pressure Control
(TPC/RDC)
OE
Press the button 1 or the but-
ton 2 to select an odometer in
the sector 3.
The following values can be dis-
played:
Total distance covered
Tripmeter 1 (Trip I)
Tripmeter 2 (Trip II)
Operating range (after reaching
reserve level)
with onboard computer
OE
or
with Tire Pressure Control
(TPC/RDC)
OE
Press the button 2 to select an
odometer in the sector 3.
The following values can be dis-
played:
Total distance covered
Tripmeter 1 (Trip I)
Tripmeter 2 (Trip II)
Press the button 1 to select a
display in the sector 4.
with onboard computer
OE
The following values can be dis-
played:
Clock (CLOCK)
Ambient temperature (TEMP)
Average speed (ØSPEED)
Average consumption
(ØFUEL)
Range (RANGE)
Oil level indicator (OIL)
4
43
z Operation

BMW 2011 R 1200 GS Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Power	110 hp (81 kW) at 7, 750 rpm
Compression Ratio	12.0:1
Fuel System	Electronic fuel injection
Final Drive	Shaft drive
ABS	Standard
Front Tire	110/80 R19
Rear Tire	150/70 R17
Dry Weight	203 kg
Weight, ready to ride, fully fueled	229 kg
Engine Type	Air/oil-cooled flat twin ('Boxer')
Torque	120 Nm at 6, 000 rpm
Fuel Type	Unleaded premium
Transmission	6-speed
Frame	Two-section frame consisting of front and rear sections
Front Suspension	Telelever
Rear Suspension	Paralever
Front Brake	Dual disc
Rear Brake	Single disc
Seat Height	850 mm
Wheelbase	1507 mm
Fuel Capacity	20.0 l
