BMW 2011 R 1200 GS User Manual

Spring preload on front
wheel
Spring preload at position 5
(For offroad use)
Adjusting spring preload
for rear wheel
Make sure ground is level and
firm and park motorcycle.
Your motorcycle's han-
dling will suffer if you do
not match the spring-preload and
damping-characteristic settings.
Adjust the damping characteristic
to suit the spring preload.
Adjusting the spring preload
while the motorcycle is be-
ing ridden can lead to accidents.
Adjust the spring preload
only when the motorcycle is
stationary.
To decrease spring preload,
turn handwheel 1 in direction
of arrow LOW.
To increase spring preload,
turn handwheel 1 in direction
of arrow HIGH.
Basic setting of spring
preload, rear
without Electronic Suspen-
sion Adjustment (ESA)
OE
Turn adjustment wheel as
far as possible toward LOW,
then pretension spring with
10 clicks. (Full tank of gas,
with rider 187 lbs (85 kg))
The number of visible grooves
(five on the LOW stop) can be
used to determine the current
setting.
Damping
Setting
The damping must be adjusted
to the road conditions and the
spring preload.
A rough road surface requires
softer damping than a smooth
road surface.
An increase in spring preload
requires firmer damping, a re-
4
55
z Operation

BMW 2011 R 1200 GS Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Power	110 hp (81 kW) at 7, 750 rpm
Compression Ratio	12.0:1
Fuel System	Electronic fuel injection
Final Drive	Shaft drive
ABS	Standard
Front Tire	110/80 R19
Rear Tire	150/70 R17
Dry Weight	203 kg
Weight, ready to ride, fully fueled	229 kg
Engine Type	Air/oil-cooled flat twin ('Boxer')
Torque	120 Nm at 6, 000 rpm
Fuel Type	Unleaded premium
Transmission	6-speed
Frame	Two-section frame consisting of front and rear sections
Front Suspension	Telelever
Rear Suspension	Paralever
Front Brake	Dual disc
Rear Brake	Single disc
Seat Height	850 mm
Wheelbase	1507 mm
Fuel Capacity	20.0 l
