BMW 2011 R 1200 GS User Manual

Rear brake fluid level
Brake fluid (DOT4)
The brake fluid level must
not fall below the MIN mark.
(Brake-fluid reservoir hori-
zontal, motorcycle standing
upright)
If brake fluid level drops below
permissible level:
Have the defect corrected as
soon as possible by a special-
ized workshop, preferably an
authorized BMW Motorrad re-
tailer.
Clutch
Checking clutch operation
Pull the clutch lever.
Pressure point must be clearly
perceptible.
If no clear pressure point can be
felt:
Have the clutch checked
by a specialized workshop,
preferably an authorized BMW
Motorrad retailer.
Checking clutch fluid level
Make sure ground is level and
firm and place motorcycle on
its center stand.
Move handlebars into straight-
ahead position.
Read off clutch fluid level at
reservoir 1.
The fluid level in the clutch
fluid reservoir rises due to
clutch wear.
Clutch fluid level (visual
check)
Clutch fluid level must not
drop. (Motorcycle stand-
ing upright with handlebars
straight ahead)
If clutch fluid level drops:
8
103
z Maintenance

BMW 2011 R 1200 GS Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Power	110 hp (81 kW) at 7, 750 rpm
Compression Ratio	12.0:1
Fuel System	Electronic fuel injection
Final Drive	Shaft drive
ABS	Standard
Front Tire	110/80 R19
Rear Tire	150/70 R17
Dry Weight	203 kg
Weight, ready to ride, fully fueled	229 kg
Engine Type	Air/oil-cooled flat twin ('Boxer')
Torque	120 Nm at 6, 000 rpm
Fuel Type	Unleaded premium
Transmission	6-speed
Frame	Two-section frame consisting of front and rear sections
Front Suspension	Telelever
Rear Suspension	Paralever
Front Brake	Dual disc
Rear Brake	Single disc
Seat Height	850 mm
Wheelbase	1507 mm
Fuel Capacity	20.0 l
