BMW G 650 XCOUNTRY Rider's Manual

Coolant
Checking coolant level
Make sure the ground is level
and firm and hold the motorcy-
cle vertically.
Check coolant level on scale 1
of coolant expansion tank.
Coolant, specified level
between MIN and MAX
marks on expansion tank
If coolant level is too low:
Add coolant.
If coolant level is too high:
Contact a specialized work-
shop, preferably an authorized
BMW Motorrad retailer.
Topping up coolant
Pull out radiator cap cover 1
toward front.
Open cap of coolant expansion
tank 2.
8
67
z Maintenance

BMW G 650 XCOUNTRY Specifications

General

Engine Type	Single-cylinder, four-stroke
Displacement	652 cc
Max Torque	60 Nm (44 lb-ft) at 5, 250 rpm
Transmission	5-speed
Fuel System	Electronic fuel injection
Front Suspension	45 mm telescopic fork
Max Power	53 hp (39 kW) at 7, 000 rpm
Fuel Capacity	9.5 liters
Seat Height	840 mm
Front Brakes	Single 300 mm disc, 2-piston caliper
Rear Brakes	Single 240 mm disc with single-piston caliper
Dry Weight	148 kg
