BMW G 650 XCOUNTRY Rider's Manual

Press axle 5 inward from left
until it protrudes from clamping
on right-hand side.
Pull out axle using a screwdriv-
er.
Do not remove grease on axle.
Remove left-hand spacer
sleeve 6.
Remove right-hand spacer
sleeve 7.
Installing front wheel
Install right-hand spacer
sleeve 7.
Install left-hand spacer
sleeve 6.
The front wheel must be
installed right way round to
rotate in the correct direction.
Observe the direction of rota-
tion arrows on the tires or on the
rim.
Roll front wheel into forks.
8
73
z Maintenance

BMW G 650 XCOUNTRY Specifications

General

Engine Type	Single-cylinder, four-stroke
Displacement	652 cc
Max Torque	60 Nm (44 lb-ft) at 5, 250 rpm
Transmission	5-speed
Fuel System	Electronic fuel injection
Front Suspension	45 mm telescopic fork
Max Power	53 hp (39 kW) at 7, 000 rpm
Fuel Capacity	9.5 liters
Seat Height	840 mm
Front Brakes	Single 300 mm disc, 2-piston caliper
Rear Brakes	Single 240 mm disc with single-piston caliper
Dry Weight	148 kg
