Fuses
Removing fuse
There is a danger of fire
if defective fuses are by-
passed.
Always replace defective fuses
with new fuses.
Switch off ignition.
Removing seat ( 38)
Press locking lever 1 and fold
open fuse cover.
Pull defective fuse out of fuse
box as shown in assignment
diagram.
If the fuses are frequently
defective, have the electri-
cal system checked by a special-
ized workshop, preferably an au-
thorized BMW Motorrad retailer.
Fuse assignment
A ABS (OE) (10 A)
B Engine management sys-
tem (15 A)
C Low-beam headlight (7.5 A)
D Brake light, horn, instru-
ment cluster, diagnosis plug
(7.5 A)
E Parking lights, license plate
light, headlight flasher, high-
beam headlight (7.5 A)
F Starter relay, turn indicators,
diagnosis plug (15 A)
G Spare fuse (15 A or 10 A
with OE)
H Spare fuse (7.5 A)
I Spare fuse (15 A)
Installing fuse
Replace defective fuse with
fuse with required amperage.
Close fuse cover.
Latch audibly engages.
Installing seat ( 39)
Removing ABS fuse
There is a danger of fire
if defective fuses are by-
passed.
Always replace defective fuses
with new fuses.
Switch off ignition.
8
80
z Maintenance

BMW G 650 XCOUNTRY Specifications

General

Engine Type	Single-cylinder, four-stroke
Displacement	652 cc
Max Torque	60 Nm (44 lb-ft) at 5, 250 rpm
Transmission	5-speed
Fuel System	Electronic fuel injection
Front Suspension	45 mm telescopic fork
Max Power	53 hp (39 kW) at 7, 000 rpm
Fuel Capacity	9.5 liters
Seat Height	840 mm
Front Brakes	Single 300 mm disc, 2-piston caliper
Rear Brakes	Single 240 mm disc with single-piston caliper
Dry Weight	148 kg
