12
PREPARATIONS
Installation requirements
Comply with local installation guidelines.
The product must be repaired in a suitable environment. The Wallbox must be protected from rain,
snow and dirt during the procedure. If it is installed outdoors, the termination panel cover and the
front part must not be opened in rain, wind, snow, etc.
Ensure access to the shut-off device and prepare suitable material to secure it to prevent it being
switched on again.
The following components must not show any signs of damage or defects during the procedure:
–
Housing or housing parts
–
Plug connectors
–
Contact points/Terminal connectors
–
Seals
–
Circuit boards
–
Signs of water ingress inside the Wallbox
WARNING
Electrical danger!
If the installation conditions are not satisfied, the spare part must not be installed. In this case,
have the action required for the repair or replacement carried out by the manufacturer.
List of tools
The following tools will be required for the installation work:
Flat screwdriver with a blade width of 5.5 mm
PH2 and PZ2 cross head screwdrivers
PH2x30 cross head screw driver (recommended for removing the connector holder)
Torx T25 screwdriver
36 mm open-ended spanner
Side cutter
Switch off the voltage supply
WARNING
The Wallbox does not have its own mains switch. The circuit breaker on the building
installation is used as a mains isolation device.
