Affix warranty seals
1. Clean the surfaces on the left and right on the
Wallbox to which the warranty seals are to be
affixed, see illustration to the left. The area
must be clean and free from dust or grease.
2. Affix the supplied warranty seals as shown to
the right and left.
IMPORTANT
Use a damp cloth or a cleaning product
suitable for plastics, such as isopropanol, to
clean the bonding areas.
Install the housing cover
Attach the housing cover
1. Attach the housing cover at the top and
ensured that the hooks on the housing cover
are correctly attached 1.
2. Press the cover downwards and then push the
housing cover 2 backwards.
The housing cover must slide into the bottom
guides without any major resistance.
IMPORTANT
Ensure that the housing cover is correctly
positioned in the housing guide on all sides.
The most only be a minimum uniform
gap.
