BMW
BMW
BMWBMW
2460.14Ća
2001
Pin Assignments
01/01
Z3
E = Input, A = Output, M = Ground
K = X70001 9 Pins, blue
L = X70003 52 Pins, blue
M = X70004 40 Pins, blue
X70001
Pin Type Signal Description/Function Connection
1 E 15<30 Voltage supply Fuse 26
2 Not used
3 Not used
4 M 31E Ground Ground point
5 M 31L Ground Ground point
6 M 31L Ground Ground point
7 E 30 Voltage supply B+ junction point E-box
8 E U_HR<4 Voltage supply Fuse holder in E-box, fuse F204
9 E U_HR<4 Voltage supply Fuse holder in E-box, fuse F204
X70003
Pin Type Signal Description/Function Connection
1 M SLM– Ground Shift-lock
2 A SLM+ Shift-lock solenoid control Shift-lock
3 A L2 Gear range signal L2 Electronic immobilizer control
module (EWS III)
4 Not used
5 Not used
6 Not used
7 Not used
8 Not used
9 Not used
10 Not used
11 Not used
