6100.0Ćb
BMW
BMW
BMW
2001
Pin Assignments
01/01
BM
BMW
BMWBMW
Z3
E = Input, A = Output, M = Ground
X13252
Pin Type Description/Function Connection
1 A Central arrest signal Lock motors
2 A Unlock signal Lock motors
3 Not used
4 A Automatic interior light signal Interior light
5 Not used
6 A Voltage supply Power window motor, driver’s door
7 A Voltage supply Power window motor, passenger’s door
8 E Power supply Front power distribution box, fuse 14
9 A Lock signal Lock motors
10 E Power supply Front power distribution box, fuse 35
11 Not used
12 E Power supply Front power distribution box, fuse 33
13 E Motor signal Power window motor, driver’s door
14 E Motor signal Power window motor, passenger’s door
15 M Ground Ground point
X13253
Pin Type Description/Function Connection
1 E Unlock signal Door lock motor, driver’s door
2 E Unlock signal Door lock motor, passenger’s door
3 E Unlock signal Luggage compartment lock motor
(not M Coupe)
4 E Data signal Anti-theft system control module (Alpine)
Central locking remote control (with DWA)
5 E Inclination signal Pitch sensor (with DWA)
6 Not used
7 E Crash signal Supplemental restraint system control
module
8 E Revolution signal Power window motor, driver’s door
9 E Revolution signal Power window motor, passenger’s door
