Pin Assignments
01/01
BM
BMW
BMWBMW
Z3
E = Input, A = Output, M = Ground
X17
Pin Type Description/Function Connection
1 E Tire pressure warning lamp control Engine control module (DME) (M Versions)
2 A Vehicle speed signal Various control modules
3 M Ground supply, terminal 31 for indicator and
warning lamps
Ground point
4 E Voltage supply, terminal 15 for instrument
cluster electronics
Front power distribution box, fuse 23
5 Not used
6 E Ground supply, terminal 61 for battery
charge indicator
Generator (Z3 Versions)
Engine control module (DME) (M Versions)
7 Not used
8 E Fog light indicator control Front power distribution box, fuse 15
9 A Sound tone signal Chime module
10 Not used
11 Not used
12 Not used
13 Not used
14 E Seat belt warning lamp control Driver’s seat belt switch
15 E SIA reset/service interval indicator reset Data link connector
16 E Voltage supply, terminal R Front power distribution box, fuse 46
17 Not used
18 Not used
19 E Oil pressure warning lamp control Oil pressure switch (Z3 Versions)
Engine control module (DME) (M Versions)
20 Not used
21 E ABS warning lamp (ABS) ABS/ASC/DSC control module
22 E Ignition key warning/audible ignition key
warning
Ignition switch
23 E Driver’s door open Driver’s door jamb switch
24 Not used
25 E Fuel consumption signal Board computer (Z3 Versions)
26 Not used
To Next Page
