Pin Assignments (Z3 Versions Late Production)
01/01
Z3
E = Input, A = Output, M = Ground
X18303
Pin Type Signal Description/Function Connection
1 E 30A52 Terminal 30 Fuse 52
2 E/A DIAG_K Diagnosis TXD signal Data link connector
3 Not used
4 E 15A21 Terminal 15 Fuse 21
5 Not used
6 E A_LAT Transverse acceleration sensor
signal
Transverse acceleration sensor
7 Not used
8 A DFAHR Wheel speed signal, right rear Engine control module (DME)
9 E BRFN Brake fluid level signal Brake fluid level switch
10 Not used
11 E/A CAN_H CAN-bus High Splice, CAN-bus High
12 Not used
13 Not used
14 Not used
15 E/A CAN_L CAN-bus Low Splice, CAN-bus Low
16 M GND Ground Ground point
17 Not used
18 E SENS_DRIV1 Pressure sensor signal Pressure sensor
19 M GND_DRIV1 Ground Pressure sensor
20 A P_DRIV1 Voltage supply Pressure sensor
21 M GND_DRIV2 Ground Pressure transmitter
22 E SENS_DRIV2 Pressure transmitter signal Pressure transmitter
23 A P_DRIV2 Voltage supply Pressure transmitter
24 M GND_YAW Ground Transverse acceleration sensor,
RPM rate sensor
25 Not used
26 A SENSP_YAW Voltage supply Transverse acceleration sensor,
RPM rate sensor
27 E HANDB Handbrake signal Handbrake switch
28 Not used
