Pin Assignments
01/01
BM
BMW
BMWBMW
Z3
E = Input, A = Output, M = Ground
N = X10182 18 Pins, black
O = X13252 15 Pins, black
P = X13253 26 Pins, yellow
Q = X13254 26 Pins, green
X10182
Pin Type Description/Function Connection
1 E Crash signal Crash control module
2 E Light signal Light switch
3 E Power supply Front power distribution box, fuse 16
(with DWA)
4 E Power supply Front power distribution box, fuse 43
5 M Ground Ground point
6 Not used
7 A Activate siren DWA siren (with DWA)
8 Not used
9 A Diagnosis RxD signal Data link connector
10 A Optical alarm Crash control module (with DWA)
11 E/A Diagnosis TxD signal Data link connector
12 E Start signal Starter (Z3 Versions)
Ignition switch (M Versions)
13 Not used
14 A Activate LED LED DWA (with DWA)
15 A Drive-away protection Electronic immobilizer control module
(EWS III)
16 Not used
17 E DWA signal Front lid micro/radio anti-theft switch
(with DWA)
18 E Power supply Front power distribution box, fuse 2
