Pin Assignments
01/01
BM
BMW
BMWBMW
Z3
E = Input, A = Output, M = Ground
X16
Pin Type Description/Function Connection
1 E High beam indicator control Combination switch
2 E Terminal 58g, instrument illumination power Light switch (dimmer)
3 E Right turn signal indicator control Hazard flasher relay
4 E Left turn signal indicator control Hazard flasher relay
5 Not used
6 E/A CAN-bus High Splice, CAN-bus High
7 E/A CAN-bus Low Splice, CAN-bus Low
8 Not used
9 Not used
10 Not used
11 Not used
12 E/A Diagnosis TXD signal Data link connector
13 Not used
14 E Air bag warning lamp (SRS) control Supplemental restraint system control
module
15 Not used
16 Not used
17 E Park brake warning lamp control Park brake switch
18 E Brake fluid warning lamp control Brake fluid level switch
19 E Brake pad wear warning lamp control Brake pad sensors
20 Not used
21 Not used
22 E Voltage supply, terminal 30 Front power distribution box, fuse 31
23 E Voltage supply, terminal 15 for indicator and
warning lamps
Front power distribution box, fuse 27
24 M Ground supply, terminal 31 for instrument
cluster electronics
Ground point
25 Not used
26 Not used
