6100.0Ćc
BMW
BMW
BMW
2001
Pin Assignments
01/01
BM
BMW
BMWBMW
Z3
E = Input, A = Output, M = Ground
Pin ConnectionDescription/FunctionType
10 Not used
11 A Consumer cut-off signal Transmission position indicator light
(Late Production)
12 Not used
13 E Central arrest signal Door lock switches
14 E Lock signal, driver’s door Door lock motor, driver’s door
15 E Lock signal, passenger’s door Door lock motor, passenger’s door
16 E Lock signal, luggage compartment lid Luggage compartment lock motor
17 E Data signal Anti-theft system control module (Alpine)
Central locking remote control (with DWA)
18 Not used
19 Not used
20 Not used
21 Not used
22 Not used
23 A Plus supply (revolution) Power window’s motor, driver’s side
24 A Voltage supply (revolution) Power window’s motor, passenger’s side
25 Not used
26 Not used
X13254
Pin Type Description/Function Connection
1 E Remote control signal Central locking remote control (with DWA)
2 E Door signal Door jamb switch, driver’s door
3 E Door signal Door jamb switch, passenger’s door
4 Not used
5 Not used
6 E OPEN signal Power window switch, driver’s door
7 E CLOSE signal Power window switch, driver’s door
8 E OPEN signal Power window switch, passenger’s door
9 E CLOSE signal Power window switch, passenger’s door
10 Not used
