Pin Assignments (Z3 Versions)
01/01
Z3
E = Input, A = Output, M = Ground
Pin ConnectionDescription/FunctionSignalType
37 A P_EVZ5 Activate valve Cyl. 5 fuel injection valve
38 A P_EVZ6 Activate valve Cyl. 6 fuel injection valve
39 Not used
40 A T_NWE1 Activate valve Variable camshaft control valve 1
(inlet)
41 A T_NWA1 Activate valve Variable camshaft control valve 2
(outlet)
42 A T_TEV Activate valve Evaporative emission valve
43 A T_MDK1 Activate motor Throttle position actuator
44 A T_MDK2 Activate motor Throttle position actuator
45 A S_KFK Cooling signal Thermostat, characteristic map
cooling
46 A T_LLFSS CLOSE signal Idle speed control valve
47 A T_LLFSO OPEN signal Idle speed control valve
48 M W_KS Ground Shield knock sensor
49 A S_DISA Activate valve Valve, individual control intake
system
50 Not used
51 Not used
52 A S_SLPV Activate valve Secondary air pump valve
X60004
Pin Type Signal Description/Function Connection
1 Not used
2 Not used
3 A S_SLP Activate relay Secondary air pump relay
4 Not used
5 Not used
6 Not used
7 M M_FWG1 Ground Pedal position sensor
8 E A_FWG1 Signal, pedal position 1 Pedal position sensor
9 A U_FWG1 Voltage supply Pedal position sensor
To Next Page
