D9412GV4/D7412GV4/D7212GV4 | Installation and Operation Guide | Appendix B: Point Address Charts
Bosch Security Systems, Inc. | 3/12 | F01U266054-01 83
B.3 SDI2 Points
Not all off-board points supported by the
control panel can be supported on B208 Octo-
input modules. Points 9 and 10, 19 and 20, etc.
can be supported by ZONEX bus or SDI2
Wireless points.
Table 29: SDI2 Points
Octo-input Module Rotary
Switch Setting
Supported Points
0 Disabled
1 11 - 18
2 21 - 28
3 31 - 38
3
4 41 - 48
5 51 - 58
6 61 - 68
7 71 - 78
2
8 81 - 88
9 91 - 98
10 101 - 108
11 111 - 118
12 121 - 128
13 131 - 138
14 141 - 148
15 151 - 158
16 161 - 168
17 171 - 178
18 181 - 188
19 191 - 198
20 201 - 208
21 211 - 218
22 221 - 228
23 231 - 238
24 241 - 248
1
1
The D9412GV4 supports points 1 to 247 and modules 1-
24. Terminate point 248 with an EOL resistor.
2
The D7412GV4 supports points 1 to 75 and modules 1 -
7. Terminate points 76, 77, and 78 with EOL resistors.
3
The D7212GV4 supports points 1 to 40 and modules 1 –
3.
