Technical data
Standard charger
Input: 207 to 264 V ~ (47-63 Hz)
Output: 36 V
4 A
Frequency: 47 to 63 Hz
Storage temperature: -10 °C to +50 °C
Permissible charging temperature: 0 °C to +40 °C
Rechargeable battery type: PowerPack 300 (30 cells)
PowerPack 400 (40 cells)
PowerPack 500 (50 cells)
Charging time for PowerPack
300/400/500: 2.5 h / 3.5 h / 4.5 h
Weight (according
to EPTA procedure 01-2003): 800 g
IP code: IP40*
Compact charger
Input: 90 to 264 V ~ (47-63 Hz)
Output: 36 V
2 A
Frequency: 47 to 63 Hz
Storage temperature: -10 °C to +50 °C
Permissible charging temperature: 0 °C to +40 °C
Rechargeable battery type: PowerPack 300 (30 cells)
PowerPack 400 (40 cells)
PowerPack 500 (50 cells)
Charging time for PowerPack
300/400/500: 5 h / 6.5 h / 7.5 h
Weight (according
to EPTA procedure 01-2003): 600 g
Protection class: IP40*
* IP40: Protection against debris with a diameter of 1 mm or
greater.
* IP54: Protection against harmful amounts of dust and
splashing water from all sides.

Bosch Performance Line Specifications

General

Motor Type	Mid-drive
Drive Unit Weight	3.2 kg
Nominal Power	250 W
Walk Assistance	Yes
Battery Voltage	36 V
Max Speed	25 km/h (EU), 20 mph (US)
Assistance Levels	Eco, Tour, Sport, Turbo
Display	Intuvia, Nyon, Purion, Kiox
Compatibility	Bosch eBike systems
