The device is not resistant to gas jeopardizing the function [sulphur
dioxide (SO
2
), hydrogen sulphide (H
2
S)].
Failure of the product due to contaminated air
● The ambient air must not contain acids, alkaline solutions, corrosive agents,
salts, metal vapors and other electrically conductive contaminants in high
concentrations
● The devices to be installed into the housing and installation compartments
must at least comply with the degree of protection IP 54 according to DIN EN
60529.
● The device shall be provided in a suitable fire enclosure in the end-use
application.
This is a product that corresponds to the limit values of the emitted
interference of class A (industrial environments), but not of class B
(residential area and small enterprises).
When using the product in residential areas or small enterprises, the
operator has to take actions to prevent radio interferences (also
refer to DIN EN 55022).
7
Technical data
PC box Type L Type M Type N Type P Type Q Type R
Processor Depending on the configuration, the following processors are available for all
types:
● Intel® Core™ i7-6820EQ 2.8 GHz Quad Core Turbo Boost 3.5 GHz 8 MB L2
cache
● Intel® Core™ i5-6300U 2.4 GHz Dual Core Turbo Boost 3.0 GHz 3 MB cache
● Intel® Celeron® 3955U 2.0 GHz Dual Core 2 MB cache
Chip set The following chip sets are used depending on the processor:
● Core™ i7-6820EQ 2.8 GHz:
Intel® QM170
● Core™ i5-6300U 2.4 GHz:
Intel® 100 Series PCH-LP integrated in the multi-chip package
● Celeron® C3955U 2.0 GHz:
Intel® 100 Series PCH-LP integrated in the multi-chip package
10/57
Technical data
IndraControl VPB 40.4
Bosch Rexroth AG R911376309_Edition 02
