Danger without safe separation!
WARNING
The 24 V DC input voltage must comply with the requirements of the "safe
separation"!
Plug and remove the plug connection only if there is no voltage!
Conductor cross-sections permitted for the spring terminal at X10
Conductors Cross-section
Conductor cross-section inflexible, max.
10 mm
2
Conductor cross-section inflexible, recommended
2.5 mm
2
Conductor cross-section flexible, max.
6 mm
2
Conductor cross-section flexible, recommended
2.5 mm
2
Conductor cross-section flexible with core end sleeves without plastic sleeve,
max.
6 mm
2
Conductor cross-section flexible with core end sleeves without plastic sleeve,
recommended
2.5 mm
2
Conductor cross-section flexible with core end sleeves with plastic sleeve, max.
4 mm
2
Conductor cross-section flexible with core end sleeves with plastic sleeve,
recommended
2.5 mm
2
Conductor cross-section AWG/kcmil, max. 8
Conductor cross-section AWG/kcmil, recommended 13
9.3 USB interfaces XUSB1 to XUSB6
The devices are provided with six USB interfaces on the connector panel
(XUSB1/2 XUSB3/4 and XUSB5/6). There is another USB 3.0 interface in the
housing, refer to chapter 9.8 "Internal interfaces" on page 20.
XUSB1/XUSB2
each port 500 mA
XUSB3/XUSB4
each port 500 mA
XUSB5/XUSB6
each port 900 mA
Maximum
power consumption
Maximum total power
consumption without
plug-in cards: 3,8 A
Maximum total power
consumption with
plug-in cards: 1,5 A
USB 3.0
USB 2.0
USB 2.0
Fig. 9-3:
Current carrying capacity of the six USB connections
①: The USB ports are monitored in pairs. If, e. g. XUSB1 switches
off, as the power consumption has been exceeded (> 500 mA),
XUSB2 switches off as well.
IndraControl VPB 40.4 17/57
Interfaces
R911376309_Edition 02 Bosch Rexroth AG
