Bose FreeSpace IZA 2120-HZ Service Manual

39
ELECTRICAL PART LIST
FreeSpace
®
IZA 2120-HZ and ZA 2120-HZ SMPS PCB Assembly
Miscellaneous (continued)
Reference
Designator
Description
V
endo
r
Part
Number
Note
SCREW SCREW, M3X10, W/S&F, WASHER, (BLK) 2900-3010
SCREW, M3 SCREW, MACHINE, PAN, M3X8, CROSS-
RECESS, BZ
2900-3008
SILICON INSULATN-SHEET, SIL-PAD, 800, 18X13 3101-0611
T200 TRANS, PWR, 385V/160V, 300W, 1A, ER40 1806-4233 3
T201 CHOKE, COMMON, MODE, 10MH, MIN, 5A, AT 1805-0090 3
T202 CHOKE, COIL, 940UH, 15%, 8A, MIN 1805-0520 3
T203 CHOKE, COMMON, MODE, 10MH, MIN, 5A, AT 1805-0090 3
T204 TRANS, PWR, 385V, 40W, ER28 1806-4236 3
WASHER WASHER, METAL, ID, 3.3, 0D8, T=0.5 2600-3005

Bose FreeSpace IZA 2120-HZ Specifications

General

Maximum current	5 A
AC input voltage	230 V
AC input frequency	50 Hz
Amplifier class	D
Frequency range	55 - 20000 Hz
Audio output channels	2.0 channels
Peak power per channel	- W
Total Harmonic Distortion (THD)	0.3 %
Purpose	Performance/stage
Equalizer	Yes
Product color	Silver
Volume control	Rotary
Connectivity technology	Wired
Line inputs (RCA)	2
Speakers connectivity type	RCA
Package weight	5400 g

Weight and Dimensions

Depth	324 mm
Width	483 mm
Height	44 mm
Weight	4100 g
