Bose FreeSpace IZA 2120-HZ Service Manual

55
ELECTRICAL PART LIST
FreeSpace
®
IZA 2120-HZ DSP PCB Assembly
Integrated Circuits (continued)
Reference
Designator
Description
V
endor Part
Number
Note
U414 IC, TL072CDR, DUAL, J-FET, INPUT, OP-AMP,
(SMD)
3130-8020
U415 IC, REGULATOR, 7815, DPAK/TO-252, AUK 3132-816149
U416 IC, REGULATOR, -15V, 7915, DPAK/TO-252, AUK 3132-817149
Miscellaneous
Reference
Designator
Description
V
endor Part
Number
Note
J400 FFC, CONN., 30PIN, P1.0, TOP, ENTRY 2101-3073
J401 FFC, CONN., 30PIN, P1.0, TOP, ENTRY 2101-3073
J402 CONN, PIN, HEADER, 5P, P2.54, DIP, ST, M,
1X5P, H11.6
2101-3422
J403 WAFER, 4P, P2.0, STRAIGHT
2102-040S퍍
J404 7, PIN, WAFER, P2.0, (COULUMB)
2102-070S퍍
J405 CONN, FFC, 10P, P0.5, SMT, ST, F 2101-3375
J406 CONNECTOR, FFC, 25P, P1.0, TOP, ENTRY 2101-3043
X400 CRYSTAL, 24.576MHZ20PPM, SM, HC-49-SMD 2300-3290
X401 CRYSTAL, 12MHZ, -40, C, SMD 2300-2430
FreeSpace IZA 2120-HZ Front PCB Assembly
Resistors
Reference
Designator
Description
V
endor Part
Number
Note
R900 RMG, 1/16W, 100R, 1%, 0603 4723-101A
R901 RMG, 1/16W, 5.1K, 1%, 0603/1608 4723-512A
R902 RMG, 1/16W, 5.1K, 1%, 0603/1608 4723-512A
R903 RMG, 1/16W, 5.1K, 1%, 0603/1608 4723-512A
R904 RMG, 1/16W, 715R, 1%, 0603 4723-7150
R905 RMG, 1/16W, 715R, 1%, 0603 4723-7150
R906 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R907 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R908 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R909 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R910 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R911 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R912 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R913 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R914 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R915 RMG, 1/16W, 100R, 1%, 0603 4723-101A
R916 RMG, 1/16W, 100R, 1%, 0603 4723-101A
R917 RMG, 1/16W, 100R, 1%, 0603 4723-101A
R918 RMG, 1/16W, 100R, 1%, 0603 4723-101A
R919 RMG, 1/16W, 100R, 1%, 0603 4723-101A
R920 RMG, 1/16W, 100R, 1%, 0603 4723-101A
R921 RMG, 1/16W, 100R, 1%, 0603 4723-101A
R922 RMG, 1/10W, 100R, 1%, 0805 4720-101A
R923 RMG, 1/10W, 100R, 1%, 0805 4720-101A
R924 RMG, 1/16W, 1M, 1%, 0603 4723-105A
R925 RMG, 1/16W, 1M, 1%, 0603 4723-105A
R926 RMG, 1/10W, 24.3K, 1%, 0603 4720-2432

Bose FreeSpace IZA 2120-HZ Specifications

General

Maximum current	5 A
AC input voltage	230 V
AC input frequency	50 Hz
Amplifier class	D
Frequency range	55 - 20000 Hz
Audio output channels	2.0 channels
Peak power per channel	- W
Total Harmonic Distortion (THD)	0.3 %
Purpose	Performance/stage
Equalizer	Yes
Product color	Silver
Volume control	Rotary
Connectivity technology	Wired
Line inputs (RCA)	2
Speakers connectivity type	RCA
Package weight	5400 g

Weight and Dimensions

Depth	324 mm
Width	483 mm
Height	44 mm
Weight	4100 g
