Bose FreeSpace IZA 2120-HZ Service Manual

4
Product Information
Material Master # Description Region
719782-0420 FREESPACE IZA 2120-LZ No Power cord No Power Cord
719782-1420 FREESPACE IZA 2120-LZ 120V NA 120V US
719782-2420 FREESPACE IZA 2120-LZ 230V EU 230V EU
719782-3420 FREESPACE IZA 2120-LZ 100V JPN 100V JPN
719782-4420 FREESPACE IZA 2120-LZ 230V UK 230V UK
719782-5420 FREESPACE IZA 2120-LZ 240V AUS 240V AU
722196-0420 FREESPACE ZA 2120-LZ No Power Cord No Power Cord
722196-1420 FREESPACE ZA 2120-LZ 120V NA 120V US
722196-2420 FREESPACE ZA 2120-LZ 230V EU 230V EU
722196-3420 FREESPACE ZA 2120-LZ 100V JPN 100V JPN
722196-4420 FREESPACE ZA 2120-LZ 230V UK 230V UK
722196-5420 FREESPACE ZA 2120-LZ 240V AUS 240V AU
719782-0410 FREESPACE IZA 2120-LZ No Power cord No Power Cord
719782-1410 FREESPACE IZA 2120-HZ 120V NA 120V US
719782-2410 FREESPACE IZA 2120-HZ 230V EU 230V EU
719782-3410 FREESPACE IZA 2120-HZ 100V JPN 100V JPN
719782-4410 FREESPACE IZA 2120-HZ 230V UK 230V UK
719782-5410 FREESPACE IZA 2120-HZ 240V AUS 240V AU
722196-0410 FREESPACE ZA 2120-HZ No Power cord No Power Cord
722196-2410 FREESPACE ZA 2120-HZ 230V EU 230V EU
722196-1410 FREESPACE ZA 2120-HZ 120V NA 120V US
722196-3410 FREESPACE ZA 2120-HZ 100V JPN 100V JPN
722196-4410 FREESPACE ZA 2120-HZ 230V UK 230V UK
722196-5410 FREESPACE ZA 2120-HZ 240V AUS 240V AU
Manufactured Versions
Overview:
The IZA/ZA 2120-HZ/LZ amplifier are new Pro installed business music systems, consisting of
four separate chassis. The product family is similar to the current IZA amplifier product line, but
whereas those amps are half-width chassis, the IZA/ZA 2120-HZ/LZ chassis are full width.
Of the four chassis, two have internal DSP with switch selections for Bose
®
Professional
speakers (Hi-Z Master and Lo-Z Master) as well as a paging input along with 2 channels of
amplifier output. The other 2 chassis are slave amplifier units, Hi-Z and Lo-Z also. They have
only 2 analog inputs and are meant to be driven by one of the master amp versions.
120W x 2, Supported Hi-z and Lo-z speakers. The Marketing Names for these products are:
IZA 2120-HZ, ZA 2120-HZ, IZA 2120-LZ and ZA 2120-LZ.
All four amplifier versions share a similar architecture. As a result, some of the PCB assemblies
are common across product versions.
In the IZA 2120-HZ and ZA 2120-HZ, the SMPS PCB, Amplifier PCB and the LED PCB are com-
mon. The Rear Panel PCB is different for these two amplifiers. The ZA 2120-HZ does not have a
DSP PCB or a Front Panel PCB.
In the IZA 2120-LZ and ZA 2120-LZ, the SMPS PCB, Amplifier PCB and the LED PCB are com-
mon. The Rear Panel PCB is different for these two amplifiers. The ZA 2120-LZ does not have a
DSP PCB or a Front Panel PCB.
PCB Usage Per Amplifier Version

Bose FreeSpace IZA 2120-HZ Specifications

General

Maximum current	5 A
AC input voltage	230 V
AC input frequency	50 Hz
Amplifier class	D
Frequency range	55 - 20000 Hz
Audio output channels	2.0 channels
Peak power per channel	- W
Total Harmonic Distortion (THD)	0.3 %
Purpose	Performance/stage
Equalizer	Yes
Product color	Silver
Volume control	Rotary
Connectivity technology	Wired
Line inputs (RCA)	2
Speakers connectivity type	RCA
Package weight	5400 g

Weight and Dimensions

Depth	324 mm
Width	483 mm
Height	44 mm
Weight	4100 g
