Bose FreeSpace IZA 2120-HZ Service Manual

59
Resistors (continued)
ELECTRICAL PART LIST
FreeSpace IZA 2120-HZ Rear Panel PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
R785 RMG, 1/16W, 100K, 1%, 0603 4723-104A+P-R
R786 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R787 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R794 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R795 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R796 RMG, 1/16W, 100K, 1%, 0603 4723-104A+P-R
R797 RMG, 1/16W, 100K, 1%, 0603 4723-104A+P-R
R798 RMG, 1/16W, 100K, 1%, 0603 4723-104A+P-R
R799 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R800 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R801 RMG, 1/16W, 100K, 1%, 0603 4723-104A+P-R
R802 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R803 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R804 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R805 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R806 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R807 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R808 RMG, 1/16W, 100R, 1%, 0603 4723-101A+P
R809 RMG, 1/16W, 100R, 1%, 0603 4723-101A+P
R814 RMG, 1/10W, 100R, 1%, 0805 4720-101A+J
R815 RMG, 1/10W, 100R, 1%, 0805 4720-101A+J
R816 RMG, 1/10W, 100R, 1%, 0805 4720-101A+J
R817 RMG, 1/10W, 100R, 1%, 0805 4720-101A+J
R820 RMG, 1/10W, 100R, 1%, 0805 4720-101A+J
R821 RMG, 1/10W, 100R, 1%, 0805 4720-101A+J
R822 RMG, 1/10W, 100R, 1%, 0805 4720-101A+J
R823 RMG, 1/10W, 100R, 1%, 0805 4720-101A+J
R824 RMG, 1/10W, 100R, 1%, 0805 4720-101A+J
R825 RMG, 1/10W, 100R, 1%, 0805 4720-101A+J
R842 RMG, 1/16W, 15R, 5%, 0603 4723-150J+P-R
R847 RMG, 1/16W, 150R, 1%, 0603 4723-151A+P-R
R848 RMG, 1/16W, 150R, 1%, 0603 4723-151A+P-R
R849 RMG, 1/16W, 150R, 1%, 0603 4723-151A+P-R
R850 RMG, 1/16W, 150R, 1%, 0603 4723-151A+P-R
R852 RMG, 1/16W, 2.2K, 1%, 0603/1608 4723-222A+P
R854 RMG, 1/16W, 2.2K, 1%, 0603/1608 4723-222A+P
R857 RMG, 1/16W, 2K, 1%, 0603/1608 4723-202A+P
R858 RMG, 1/16W, 2K, 1%, 0603/1608 4723-202A+P
R864 RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A+P
R868 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R869 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R870 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R871 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R872 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R873 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R876 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R877 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R878 RMG, 1/16W, 5.1K, 1%, 0603/1608 4723-512A+P
R879 RMG, 1/16W, 5.1K, 1%, 0603/1608 4723-512A+P
R880 RMG, 1/16W, 0R, 1%, 0603 4723-000A+P
R881 RMG, 1/16W, 0R, 1%, 0603 4723-000A+P
R882 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R

Bose FreeSpace IZA 2120-HZ Specifications

General

Maximum current	5 A
AC input voltage	230 V
AC input frequency	50 Hz
Amplifier class	D
Frequency range	55 - 20000 Hz
Audio output channels	2.0 channels
Peak power per channel	- W
Total Harmonic Distortion (THD)	0.3 %
Purpose	Performance/stage
Equalizer	Yes
Product color	Silver
Volume control	Rotary
Connectivity technology	Wired
Line inputs (RCA)	2
Speakers connectivity type	RCA
Package weight	5400 g

Weight and Dimensions

Depth	324 mm
Width	483 mm
Height	44 mm
Weight	4100 g
