Bose FreeSpace IZA 2120-HZ Service Manual

91
ELECTRICAL PART LIST
FreeSpace
®
IZA 2120-LZ Rear Panel PCB Assembly
Resistors
Reference
Designator
Description
V
endor Part
Number
Note
R700 RMG, 1/16W, 27K, 1%, 0603/1608 4723-273A+P
R701 RMG, 1/16W, 27K, 1%, 0603/1608 4723-273A+P
R702 RMG, 1/16W, 3K, 1%, 0603 4723-302A+P
R703 RMG, 1/16W, 3K, 1%, 0603 4723-302A+P
R704 RMG, 1/16W, 47K, 1%, 0603 4723-473A+P-R
R705 RMG, 1/16W, 47K, 1%, 0603 4723-473A+P-R
R706 RMG, 1/16W, 5.1K, 1%, 0603/1608 4723-512A+P
R707 RMG, 1/16W, 5.1K, 1%, 0603/1608 4723-512A+P
R708 RMG, 1/16W, 5.1K, 1%, 0603/1608 4723-512A+P
R709 RMG, 1/16W, 5.1K, 1%, 0603/1608 4723-512A+P
R710 RMG, 1/8W, 0R, 1%, 1206 4721-000A+6
R711 RMG, 1/8W, 0R, 1%, 1206 4721-000A+6
R714 RMG, 1/16W, 4.99K, 1%, 0603 4723-4991+P
R715 RMG, 1/16W, 4.99K, 1%, 0603 4723-4991+P
R716 RMG, 1/16W, 4.99K, 1%, 0603 4723-4991+P
R717 RMG, 1/16W, 4.99K, 1%, 0603 4723-4991+P
R719 RMG, 1/16W, 9.76K, 1%, 0603 4723-9761+P
R720 RMG, 1/16W, 0R, 1%, 0603 4723-000A+P
R721 RMG, 1/16W, 0R, 1%, 0603 4723-000A+P
R727 RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A+P
R729 RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A+P
R731 RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A+P
R732 RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A+P
R739 RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A+P
R740 RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A+P
R741 RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A+P
R742 RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A+P
R743 RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A+P
R744 RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A+P
R745 RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A+P
R746 RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A+P
R747 RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A+P
R749 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R752 RMG, 1/16W, 10R, 1%, 0603 4723-100A+P-R
R753 RMG, 1/16W, 10R, 1%, 0603 4723-100A+P-R
R754 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R755 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R756 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R757 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R758 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R759 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R760 RMG, 1/16W, 1.5K, 1%, 0603 4723-152A+P-R
R761 RMG, 1/16W, 2.7K, 1%, 0603/1608 4723-272A+P
R762 RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A+P
R763 RMG, 1/16W, 5.1K, 1%, 0603/1608 4723-512A+P
R764 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R765 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R766 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R771 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R778 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R779 RMG, 1/16W, 100K, 1%, 0603 4723-104A+P-R
R780 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R

Bose FreeSpace IZA 2120-HZ Specifications

General

Maximum current	5 A
AC input voltage	230 V
AC input frequency	50 Hz
Amplifier class	D
Frequency range	55 - 20000 Hz
Audio output channels	2.0 channels
Peak power per channel	- W
Total Harmonic Distortion (THD)	0.3 %
Purpose	Performance/stage
Equalizer	Yes
Product color	Silver
Volume control	Rotary
Connectivity technology	Wired
Line inputs (RCA)	2
Speakers connectivity type	RCA
Package weight	5400 g

Weight and Dimensions

Depth	324 mm
Width	483 mm
Height	44 mm
Weight	4100 g
