Bose FreeSpace IZA 2120-HZ Service Manual

50
ELECTRICAL PART LIST
Resistors (continued)
FreeSpace
®
IZA 2120-HZ DSP PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
R611 RMG, 1/16W, 100R, 1%, 0603 4723-101A
R612 RMG, 1/16W, 100R, 1%, 0603 4723-101A
R613 RMG, 1/16W, 100R, 1%, 0603 4723-101A
R614 RMG, 1/16W, 100K, 1%, 0603 4723-104AR
R615 RMG, 1/16W, 100K, 1%, 0603 4723-104AR
R616 RMG, 1/16W, 1M, 1%, 0603 4723-105A
R617 RMG, 1/16W, 1R, 5%, 0603 4723-1R0J
R618 RMG, 1/16W, 1R, 5%, 0603 4723-1R0J
R621 RMG, 1/16W, 200K, 1%, 0603/1608 4723-221A
R622 RMG, 1/16W, 13K, 1%, 0603 4723-133AR
R623 RMG, 1/16W, 13K, 1%, 0603 4723-133AR
R635 RMG, 1/16W, 22K, 1%, 0603 4723-223AR
R646 RMG, 1/16W, 1.5K, 1%, 0603 4723-152AR
R648 RMG, 1W, 5.1R, 5%, 2512 4728-5R1J
R649 RMG, 1W, 5.1R, 5%, 2512 4728-5R1J
R650 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R651 RMG, 1/16W, 47K, 1%, 0603 4723-473AR
R652 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R653 RMG, 1/16W, 3.9K, 5%, 0603 4723-392JR
R654 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R655 RMG, 1/16W, 200K, 1%, 0603/1608 4723-204A
R656 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R657 RMG, 1/16W, 100K, 1%, 0603 4723-104AR
R658 RMG, 1/10W, 20K, 1%, 0603 4720-203A
R659 RMG, 1/16W, 47R, 1%, 0603 4723-470A
Capacitors
Reference
Designator
Description
V
endor Part
Number
Note
C400 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C401 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C402 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C403 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C404 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C405 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C406 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C407 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C408 CC, 50V, 1000P, 5%, 0603, X7R 150F-102JAC
C409 CC, 50V, 1000P, 5%, 0603, X7R 150F-102JAC
C410 CC, 50V, 1000P, 5%, 0603, X7R 150F-102JAC
C411 CC, 50V, 1000P, 5%, 0603, X7R 150F-102JAC
C412 CC, 50V, 1000P, 5%, 0603, X7R 150F-102JAC
C413 CC, 25V, 10U, 10%, 1206, 3.2X1.6, X5R 150E-106KCF
C414 CC, 50V, 0.01U, 5%, 0603 150F-103JAC
C415 CC, 50V, 0.01U, 5%, 0603 150F-103JAC
C416 CT, 16V, 10U, 20%, SMD, 1.6X3.2 154D-106MCF
C417 CT, 16V, 47U, 10%, SMD, 85C, 6.0X3.2 154D-476KKF
C418 CE, 10V, 22U, 20%, SM, 3X5.3, 85C-2000H 157C-226MEJ
C419 CC, 6.3V, 22U, 10%, 1206, 3.2X1.6 150B-226KCF
C420 CC, 6.3V, 22U, 10%, 1206, 3.2X1.6 150B-226KCF
C426 CC, 16V, 1U, 10%, 0603, 0.8X1.6 150D-105KAC
C427 CC, 50V, 33PF, 5%, 0603, C0G 150F-330JAC

Bose FreeSpace IZA 2120-HZ Specifications

General

Maximum current	5 A
AC input voltage	230 V
AC input frequency	50 Hz
Amplifier class	D
Frequency range	55 - 20000 Hz
Audio output channels	2.0 channels
Peak power per channel	- W
Total Harmonic Distortion (THD)	0.3 %
Purpose	Performance/stage
Equalizer	Yes
Product color	Silver
Volume control	Rotary
Connectivity technology	Wired
Line inputs (RCA)	2
Speakers connectivity type	RCA
Package weight	5400 g

Weight and Dimensions

Depth	324 mm
Width	483 mm
Height	44 mm
Weight	4100 g
