Bose FreeSpace IZA 2120-HZ Service Manual

46
ELECTRICAL PART LIST
Miscellaneous
FreeSpace
®
IZA 2120-HZ and ZA 2120-HZ Amplifier PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
AMP HIZ SCREW, MACHINE, PAN, M3X8, CROSS-
RECESS, BZ
2900-3008
HS AMP HIZ SCREW, MACHINE, PAN, M3X8, CROSS-
RECESS, BZ
2900-3008
HS AMP HIZ HEATSINK, AMP, 62X23.1, L= 5401-0282
J1 WAFER, 4P, P2.0, STRAIGHT 2102-040S
J2 WAFER, 4P, P3.96, STRAIGHT, MALE 2101-3053
J3 WAFER, 4P, P3.96, STRAIGHT, MALE 2101-3053
J5 CONN, FFC, 10P, P0.5, SMT, ST 2101-3375
SILICON INSULATN-SHEET, SLI-800, 96X21 3101-0701
T1 TRANS, CURRENT, SENSE, 20A, EE8.3 1806-4237
T2 TRANS, CURRENT, SENSE, 20A, EE8.3 1806-4237
T3 TRANS, CURRENT, SENSE, 20A, EE8.3 1806-4237
T4 TRANS, CURRENT, SENSE, 20A, EE8.3 1806-4237
Capacitors
FreeSpace IZA 2120-HZ and ZA 2120-HZ LED & Output PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
C701 CC, 630V, 1000P, 10%, 1206 150M-102KCF
C702 CC, 630V, 1000P, 10%, 1206 150M-102KCF
C703 CC, 630V, 1000P, 10%, 1206 150M-102KCF
C704 CC, 630V, 1000P, 10%, 1206 150M-102KCF
C705 CM, 400V, 0.1U, 5%, RB, 17.5X11X5 153T-104J7U
C706 CM, 400V, 0.1U, 5%, RB, 17.5X11X5 153T-104J7U
Diodes
Reference
Designator
Description
V
endor Part
Number
Note
D950 LED, SP, 3X5, RD/GN, SUPER WHITE,
DIFFUSED, EVERLIGHT
3700-2861
D951 LED, 3MM, BLUE, SP, SLR343BB, T 225419,
ROHM
3700-2824
D952 LED, SP, 3X5, RD/GN, SUPER WHITE,
DIFFUSED, EVERLIGHT
3700-2861
Miscellaneous
Reference
Designator
Description
V
endor Part
Number
Note
J720 SOCKET, F, 2P, P5.08, 300V, 12A, GRN, ST 2113-3420
J721 SOCKET, F, 2P, P5.08, 300V, 12A, GRN, ST 2113-3420
J710 WIRE-CONN, 4P, P3.96, #18, UL1007, L=230, F/M 7013-3991
J903 SHEET, GROUND BRASS, T=0.8, TIN PLATED 4136-0991
J950 WAFER, 6 PIN, P2.0 2102-060R

Bose FreeSpace IZA 2120-HZ Specifications

General

Maximum current	5 A
AC input voltage	230 V
AC input frequency	50 Hz
Amplifier class	D
Frequency range	55 - 20000 Hz
Audio output channels	2.0 channels
Peak power per channel	- W
Total Harmonic Distortion (THD)	0.3 %
Purpose	Performance/stage
Equalizer	Yes
Product color	Silver
Volume control	Rotary
Connectivity technology	Wired
Line inputs (RCA)	2
Speakers connectivity type	RCA
Package weight	5400 g

Weight and Dimensions

Depth	324 mm
Width	483 mm
Height	44 mm
Weight	4100 g
