Bose Panaray MSA12X User Manual

38 - Design Guide
CSD Properties and Operation
Assign Beam Preset to Parameter Set
Once you assign Beam Presets for each array, you can recall a Beam Preset by invoking a Parameter set from
other ControlSpace control families (such as CC-64, GPIO, Timer in ESP, ControlSpace Remote). To do this,
you have to assign the Beam Preset to the Parameter set.
Note: You cannot assign each individual Parameter of an MSA12X device (such as Beam Gain, Beam EQ) to a
Parameter set directly. Only a Beam Preset (which is a ‘snapshot’ of the state of the array) can be assigned to
and recalled from a Parameter set.
This operation can be done while Dante is enabled, but cannot be done when CSD is online (blue
background), which is a standard CSD programming procedure. You have to go oine before setting
Parameter sets.
1. Recall the Beam Preset for the state that you want to assign to a Parameter set.
ESP/EX-1280C processor
Parameter Set
Beam Preset
Associate
MSA12X loudspeaker
Assign Beam Preset
to Parameter Set
Recall
Snapshot of status
Invoke Parameter Set with
- CC-64
- GPI trigger
- ControlSpace Remote
...etc.
