Brother ADS-2100 User Manual

2-16
Confidential
4.1.9 The page counter for the separation pad has reached the limit.
The page counters for both the separation pad and the pick-up roller have
reached the limit.
The page counter for the pick-up roller has reached the limit.
4.1.10 The front cover sensor detected an open front cover in the ready state.
The front cover sensor detected an open front cover during scanning.
4.1.11
Color parameter in the ROM does not match the first side or second side CIS unit.
4.1.12 A scanning error occurred while scanning the image.
4.1.13
The voltage value was below the lower limit during scanning.
The white level does not increase during scanning although the light intensity was increased.
A white level not within the standard was scanned when the maintenance mode function
"Acquire white level data and set CIS scan area" was executed.
A black level not within the standard was scanned when the maintenance mode function
"Acquire white level data and set CIS scan area" was executed.
<User Check>
- Replace the pick-up roller.
Step Cause Remedy
1
End of life of the separation pad
or pick-up roller
Replace the separation pad or pick-up roller.
2 Main PCB failure Replace the main PCB ASSY.
<User Check>
- Close the front cover correctly.
Step Cause Remedy
1
Front cover release lever spring
attachment failure
Reattach the front cover release lever spring.
2
Front cover release lever
attachment failure
Reattach the front cover release lever.
3
Connection failure of the front
cover sensor harness
Reconnect the front cover sensor harness.
4 Front cover sensor failure Replace the front cover sensor.
5 Main PCB failure Replace the main PCB ASSY.
Step Cause Remedy
1
First side or second side CIS
unit failure
Replace the first side or second side CIS unit.
2 Main PCB failure Replace the main PCB ASSY.
Step Cause Remedy
1 Program malfunction Reinstall the firmware.
2
First side or second side CIS
unit failure
Replace the first side or second side CIS unit.
3 Main PCB failure Replace the main PCB ASSY.
Step Cause Remedy
1
First side or second side CIS
unit failure
Replace the first side or second side CIS unit.
2 Main PCB failure Replace the main PCB ASSY.

Brother ADS-2100 Specifications

General

Film scanning	No
Color scanning	Yes
Grayscale levels	256
Input color depth	30 bit
Maximum scan size	215.9 x 863 mm
Output color depth	24 bit
ADF scan speed (b/w, A4)	24 ppm
Enhanced scan resolution	1200 x 1200 DPI
Optical scanning resolution	600 x 600 DPI
Duplex ADF scan speed (b/w, A4)	48 ipm
Scanner type	Sheet-fed scanner
Product color	Black
Scan to	E-mail, File, Image, OCR, USB
Sensor type	CMOS dual CIS
Scan drivers	ISIS, TWAIN, WIA
Internal memory	256 MB
Scan file formats	JPG, PDF, TIFF
Processor frequency	400 MHz
Scanning noise level	62.5 dB
Daily duty cycle (max)	500 pages
Auto document feeder (ADF) input capacity	50 sheets
Minimum scan area (ADF)	51 x 70 mm
ISO A-series sizes (A0...A9)	A4, A5, A6, A7, A8
Scanning media types supported	Business Card, Plain paper, Plastic Card, Recycled paper, Thick paper, Thin paper, Business card, Plastic card
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	52 - 200 g/m²
USB version	2.0
Standard interfaces	USB 2.0
Input voltage	220-240 V
Power supply type	AC
AC input frequency	50 Hz
Power consumption (off)	0.3 W
Power consumption (standby)	7 W
Power consumption (typical)	18 W
Power consumption (PowerSave)	1.5 W
Package weight	5400 g
Image formats supported	JPG, TIF
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	179 mm
Width	220 mm
Height	299 mm
Weight	3300 g
