5-110
5.1.87 Fan Motor 60 Unit
(1) Remove the Fan motor 60 unit from the Frame R.
Fig. 5-169
5.1.88 Fan Motor 60 Unit LV
(1) Remove the Fan motor 60 unit LV from the Frame R.
Fig. 5-170
Frame R
Fan motor 60 unit
Fan motor 60 unit LV
Frame R
<Right side>
