Brother DCP-8065DN Service Manual

Confidential
4-1
4.1 TRANSFERRING RECEIVED FAX DATA
When the machine at the user site requires to be repaired, unplugging the power cord from the wall
socket for sending the machine for repair will lose received FAX data if unprinted and left in the
machine.
To prevent such data loss, the service personnel should instruct end users (e.g., by telephone) to
transfer data to another facsimile machine using the procedure below.
NOTE: The number of files that can be transferred at a time
is 99. To transfer 100 files or more,
carry out the following procedure more than one time.
NOTE: This functions is not applicable to the DCP-8060/8065DN.
TIP: If there are both color and monochrome data in a file to be transferred, the monochrome data
will be transferred first. If the receiver machine does not support the color function, the
sender machine cannot transfer color data, resulting in an error.
Operating Procedure
(1) Connect the machine to be repaired (that has received data in the memory) to the telephone
line.
(2) Switch the machine on.
(2) Press the [Menu], [Start], [0], [5] and [3] keys in this order to access user-accessible
functions of the maintenance mode.
The “FAX TRANSFER” appears on the LCD.
(4) To check the number of received files
, press the [1] key.
The “1.NO. OF JOBS” appears on the LCD.
Press the [OK] key, and the number of received files appears, just as “NO. OF. JOBS:
10.”
(5) To transfer the activity report only
, press the [2] key.
The “2.ACTIVITY” appears.
To transfer received files together with the activity report
, press the [3] key.
The “3.DOCUMENTS” appears. Note that if there is no received file, the “NO
DOCUMENTS” appears.
(6) To transfer the communication list for the latest communication
, press the [4] key.
The “4.COM.LIST (NEW)” appears.
To transfer the communication list for last three errors
, press the [5] key.
The “5.COM.LIST (ERR3)” appears.
(7) With the “2.ACTIVITY,” “3.DOCUMENTS,” “4.COM.LIST (NEW),” or “5.COM.LIST
(ERR3)” being displayed, press the [OK] key.
The “ENTER NO. &SET” appears.
(8) Enter the telephone number of the receiver machine and press the [OK] key again.
NOTE: Be sure to type the telephone number with the numerical keys. No one-touch dialing
is allowed in this procedure.
The machine displays the “ACCEPTED” for approx. two seconds and starts dialing
to transfer data.
No station ID will be attached. A cover page and end page as shown on the next
page will be automatically attached, instead.

Brother DCP-8065DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Scan to	e-mail, file, image, OCR
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	28 cpm
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Internal memory	32 MB
Maximum internal memory	544 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	55 dB
Display	LCD
Market positioning	Business
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Font styles	66 Scaleable fonts, Letter, Gothic 16.66, OCR-A, OCR-B, 11 Barcodes
Dimensions (WxDxH)	531 x 450 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Scan
Color all-in-one functions	scan, n
Compatible operating systems	Mac OS X 10.2.4 or greater Windows XP
Standard interfaces	USB 2.0
Sustainability certificates	ENERGY STAR
Power consumption (standby)	85 W
Power consumption (PowerSave)	15 W
Power consumption (average operating)	660 W
