Brother HL-5380DN User Manual

Driver and Software
74
3
Software 3
Software for networks 3
BRAdmin Light 3
BRAdmin Light is a utility for initial setup of Brother network connected devices. This utility can search for
Brother products on your network, view the status and configure basic network settings, such as IP address.
The BRAdmin Light utility is available for Windows
®
2000/XP, Windows Vista
®
and Windows Server
®
2003/2008 and Mac OS X 10.3.9 (or greater) computers. For installing BRAdmin Light on Windows
®
, please
see the Quick Setup Guide we provided with the machine. For Macintosh users, BRAdmin Light will be
installed automatically when you install the printer driver. If you have already installed the printer driver, you
do not have to install it again.
For more information on BRAdmin Light, visit us at http://solutions.brother.com/
.
BRAdmin Professional 3 (for Windows
®
) 3
BRAdmin Professional 3 is a utility for more advanced management of network connected Brother devices.
This utility can search for Brother products on your network and view the device status from an easy to read
explorer style window that changes colour identifying the status of each device. You can configure network
and device settings along with the ability to update device firmware from a Windows
®
computer on your LAN.
BRAdmin Professional 3 can also log activity of brother devices on your network and export the log data in
an HTML, CSV, TXT or SQL format.
For users who want to monitor locally connected printers, install the BRPrint Auditor software on the client
PC. This utility allows you to monitor printers that are connected to a client PC via USB or parallel from
BRAdmin Professional 3.
For more information and downloading, visit us at http://solutions.brother.com/
.
Web BRAdmin (for Windows
®
) 3
Web BRAdmin is a utility for managing network connected Brother devices on your LAN and WAN. This utility
can search for Brother products on your network, view the status and configure the network settings. Unlike
BRAdmin Professional 3, which is designed for Windows
®
only, Web BRAdmin is a server based utility that
can be accessed from any client PC with a web browser that supports JRE (Java Runtime Environment). By
installing the Web BRAdmin server utility on a computer running IIS
1
, connect to the Web BRAdmin server,
which then communicates with the device itself.
For more information and downloading, visit us at http://solutions.brother.com/
.
1
Internet Information Server 4.0 or Internet Information Services 5.0/5.1/6.0/7.0

Brother HL-5380DN Specifications

General

Color	No
N-up printing	2, 4, 9, 16, 25
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Duplex print speed (black, normal quality, A4/US Letter)	6.5 ppm
Memory slots	1
Maximum internal memory	544 MB
Sound power level (standby)	35 dB
Sound pressure level (printing)	54 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	800 sheets
Multi-Purpose tray input capacity	50 sheets
Maximum duty cycle	- pages per month
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter, PCL 6
Custom media width	76.2 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	116 - 406.4 mm
Paper tray media types	Bond paper, Plain paper, Recycled paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Transparencies
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	75 W
Power consumption (printing)	675 W
Power consumption (PowerSave)	6 W
Display	LCD
Product color	Gray
Standard interfaces	Ethernet, Parallel, USB 2.0
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Server operating systems supported	Windows 2000 Advanced Server, Windows 2000 Server, Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Package weight	11.980 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	393 x 259 x 384 mm
