Brother QL-800 User Manual

Changing the Label Printer Settings
18
4
Menu Bar 4
The following explains about the menu items in the Settings Dialog Box.
• Apply Settings to the Printer
Applies the settings to the printer.
Performs the same operation as when [Apply] is clicked.
• Check Setting
Displays the current settings.
• Save Settings in Command File
Saves the specified settings in a command file.
Performs the same operation as when [Save in Command File] is selected from the [Apply] drop-down
list.
• Import
Imports the exported file.
• Export
Saves the current settings in a file.
• Factory Reset
Resets all printer settings to factory settings.
• Option Settings
If the [Do not display an error message if the current settings cannot be retrieved at startup] check
box is selected, a message will not be displayed next time.
Basic Tab 4
The following explains about the Basic Tab in the Settings Dialog Box.
•Auto Power On
Specifies whether the printer turns on automatically when the AC Power Cord is plugged into an electrical
socket.
Available settings: [On], [Off]
• Auto Power Off (AC/DC)
Specifies the period of time that passes before the printer turns off automatically when connected to an
electrical socket.
Available settings: [None], [10/20/30/40/50/60 Minutes]

Brother QL-800 Specifications

General

Color	Yes
Text alignment	Right, Center, Left
Printing colors	Black, Red
Print technology	Direct thermal
Maximum resolution	300 x 600 DPI
Maximum print height	58 mm
Minimum print length	1000 mm
Maximum printing width	60.96 mm
Maximum label width	62 mm
Maximum label length	1 m
Ethernet LAN	No
USB 2.0 ports quantity	1
Connectivity technology	Wired
PC connection	USB 2.0
Sustainability certificates	ENERGY STAR
Display	-
Product color	Black, Grey
Housing material	Plastic
Cables included	USB
Bundled software	P-touch Editor Lite P-touch Editor 5 P-touch Address Book
Cartridges quantity	2 pc(s)
Tape type	DK
Flash memory	6 MB
Number of fonts	5
Number of styles	8
Built-in barcodes	CODABAR (NW-7), Code 128 (A/B/C), Code 39, Data Matrix, EAN128, EAN13, EAN8, GS1-128, ISBN-2, ISBN-5, ITF-25, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Page description languages	Raster_P
AC input voltage	220 - 240 V
Package depth	184 mm
Package width	264 mm
Package height	232 mm
Package weight	2090 g
Label memory	99 label(s)
Number of frames	126
Languages support	CHI (SIMPL), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, HUN, ITA, JPN, NOR, POL, POR, RUS, SWE, TUR
Number of languages	18
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	213 mm
Width	125 mm
Height	142 mm
Weight	1150 g
