Brother QL-800 User Manual

63
11
11
We recommend cleaning your printer on a regular basis to maintain its correct performance.
Note
Always disconnect the AC Power Cord before cleaning the printer.
Cleaning the Exterior of the Unit 11
Wipe any dust and marks from the main unit using a soft, dry cloth.
Use a cloth slightly damp with water on difficult to remove marks.
Note
Do not use paint thinner, benzene, alcohol or any other organic solvent.
These may deform or damage the case of your printer.
Cleaning the Print Head 11
The DK Roll (thermal recording paper type) used with the machine is designed to clean the print head
automatically. When the DK Roll passes the print head during printing and label feeding, the print head is
cleaned.
Cleaning the Roller 11
Clean the roller using the Cleaning Sheet (available separately).
The printer contains only one Cleaning Sheet.
Note
When cleaning the roller, be sure to use the Cleaning Sheet supplied exclusively for this printer.
If using other Cleaning Sheet, the surface of the roller may be damaged and may cause a malfunction.
1 Turn off the power to the printer.
2 Hold the DK Roll Compartment Cover at the sides near the front of the printer and firmly lift up to open
the DK Roll Compartment Cover.
Maintenance 11

Brother QL-800 Specifications

General

Color	Yes
Text alignment	Right, Center, Left
Printing colors	Black, Red
Print technology	Direct thermal
Maximum resolution	300 x 600 DPI
Maximum print height	58 mm
Minimum print length	1000 mm
Maximum printing width	60.96 mm
Maximum label width	62 mm
Maximum label length	1 m
Ethernet LAN	No
USB 2.0 ports quantity	1
Connectivity technology	Wired
PC connection	USB 2.0
Sustainability certificates	ENERGY STAR
Display	-
Product color	Black, Grey
Housing material	Plastic
Cables included	USB
Bundled software	P-touch Editor Lite P-touch Editor 5 P-touch Address Book
Cartridges quantity	2 pc(s)
Tape type	DK
Flash memory	6 MB
Number of fonts	5
Number of styles	8
Built-in barcodes	CODABAR (NW-7), Code 128 (A/B/C), Code 39, Data Matrix, EAN128, EAN13, EAN8, GS1-128, ISBN-2, ISBN-5, ITF-25, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Page description languages	Raster_P
AC input voltage	220 - 240 V
Package depth	184 mm
Package width	264 mm
Package height	232 mm
Package weight	2090 g
Label memory	99 label(s)
Number of frames	126
Languages support	CHI (SIMPL), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, HUN, ITA, JPN, NOR, POL, POR, RUS, SWE, TUR
Number of languages	18
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	213 mm
Width	125 mm
Height	142 mm
Weight	1150 g
