Danger of hand crushing
Danger! High voltage.
No transiting while the barrier is moving
WARNING!
Important safety instructions.
READ CAREFULLY
PREMISE
• THIS PRODUCT SHOULD ONLY BE USED FOR THE PURPOSE FOR WHICH IT WAS
EXPLICITLY DESIGNED. ANY OTHER USE IS DANGEROUS. CAME S.P.A. IS NOT LIABLE
FOR ANY DAMAGE CAUSED BY IMPROPER, ERRONEOUS OR UNREASONABLE USE. •
P
RODUCT SAFETY AND CORRECT INSTALLATION ARE SUBJECT TO RESPECTING THE
PRODUCT'S TECHNICAL CHARACTERISTICS AND THE CORRECT INSTALLATION PROCE-
DURE IN LINE WITH PROFESSIONAL STANDARDS, SAFETY REGULATIONS AND USAGE
SPECIFICATIONS AS SET OUT IN THE TECHNICAL DOCUMENTATION THAT COMES WITH
THE PRODUCT. • KEEP THESE PRECAUTIONS TOGETHER WITH THE INSTALLATION AND
USAGE MANUALS THAT COME WITH THE OPERATOR SYSTEM.
B
EFORE INSTALLING
(CHECK THE CONTENTS: IF SOMETHING IS MISSING, DO NOT CONTINUE UNTIL YOU
HAVE COMPLIED WITH ALL SAFETY PROVISIONS)
• FITTING AND TESTING MUST ONLY BE PERFORMED BY QUALIFIED TECHNICIANS
• L
AY THE CABLES, INSTALL AND CONNECT UP THE PRODUCT, AND RUN TEST-
ING FOLLOWING PROFESSIONAL PROCEDURES IN COMPLIANCE WITH THE STANDARDS
AND REGULATIONS IN FORCE • BEFORE BEGINNING ANY OPERATION, READ ALL
INSTRUCTIONS CAREFULLY; INCORRECT INSTALLATION MAY CAUSE SERIOUS HARM TO
PEOPLE OR PROPERTY • MAKE SURE THE BOOM IS IN GOOD MECHANICAL ORDER,
BALANCED AND ALIGNED, AND THAT IT OPENS AND CLOSES PROPERLY. IF REQUIRED,
FIT SUITABLE PROTECTIVE DEVICES OR USE SUITABLE ADDITIONAL SAFETY SENSORS
• I
F THE OPERATOR IS TO BE INSTALLED AT A HEIGHT OF OVER 2.5 M FROM THE
GROUND OR OTHER ACCESS LEVEL, MAKE SURE YOU HAVE ANY NECESSARY PROTEC-
TIVE DEVICES OR WARNINGS IN PLACE • MAKE SURE THAT THE OPENING AUTOMATIC
BARRIER DOES NOT CREATE A HAZARD • DO NOT INSTALL THE OPERATOR UPSIDE
DOWN OR ON ELEMENTS THAT COULD BEND. IF NECESSARY, ADD SUITABLE REIN-
FORCEMENTS TO THE ANCHORING POINTS • MAKE SURE THE TEMPERATURE RANGE
SHOWN ON THE OPERATOR IS SUITABLE FOR THE INSTALLATION SITE • DO NOT
INSTALL ON SLOPING OR UNEVEN SURFACES • MAKE SURE ANY SPRINKLER SYSTEMS
CANNOT WET THE OPERATOR FROM THE GROUND UP.
I
NSTALLATION
• SUITABLY SECTION OFF AND DEMARCATE THE ENTIRE INSTALLATION SITE TO PRE-
VENT UNAUTHORISED PERSONS FROM ENTERING THE AREA, ESPECIALLY MINORS AND
CHILDREN • BE CAREFUL WHEN HANDLING OPERATORS THAT WEIGH OVER 20 KG.
I
F NEED BE, USE PROPER SAFETY HOISTING EQUIPMENT • THE CE-MARKED SAFETY
DEVICES (PHOTOCELLS, STEPPING PLATES, SAFETY EDGES, EMERGENCY BUTTONS,
ETC.) MUST BE FITTED IN COMPLIANCE WITH PROFESSIONAL STANDARDS AND THE
REGULATIONS IN FORCE, TAKING INTO ACCOUNT THE ENVIRONMENT, TYPE OF SER-
VICE REQUIRED AND THE WORKING FORCES APPLIED TO THE MOVING BARRIERS.
A
NY POINTS AT WHICH THERE IS A RISK OF CRUSHING, SHEARING OR CONVEYING
MUST BE SENSOR-PROTECTED • ANY RESIDUAL RISKS MUST BE CLEARLY SHOWN •
A
LL OPENING CONTROLS (BUTTONS, KEY-SWITCH SELECTORS, MAGNETIC READERS,
ETC.) MUST BE INSTALLED AT LEAST 1.85 M FROM THE PERIMETER OF THE BAR-
RIER'S WORKING AREA, OR WHERE THEY CANNOT BE REACHED FROM THE OUTSIDE
THROUGH THE BARRIER. ANY DIRECT CONTROLS (BUTTONS, TOUCH PANELS, ETC.)
MUST BE INSTALLED AT LEAST 1.5 M FROM THE GROUND AND MUST NOT BE ACCES-
SIBLE TO UNAUTHORISED PERSONS • THE AUTOMATIC BARRIER MUST BEAR VISIBLE
IDENTIFICATION DATA. • BEFORE CONNECTING THE BARRIER TO THE POWER SUPPLY,
MAKE SURE THAT THE IDENTIFICATION DATA CORRESPOND TO THE MAINS DATA • THE
AUTOMATIC BARRIER MUST BE CONNECTED TO AN EFFECTIVE EARTHING SYSTEM THAT
COMPLIES WITH LEGAL STANDARDS.
• T
HE MANUFACTURER DECLINES ALL LIABILITY FOR USE OF NON-ORIGINAL PROD-
UCTS, WHICH WOULD ALSO RESULT IN WARRANTY LOSS • ALL HOLD-TO-RUN CON-
TROLS MUST BE FITTED IN PLACES FROM WHICH THE MOVING BARRIER AND TRANSIT/
MANOEUVRING AREAS ARE VISIBLE • WHERE MISSING, APPLY A PERMANENT SIGN
SHOWING THE POSITION OF THE RELEASE DEVICE • BEFORE DELIVERING THE PROD-
UCT TO THE USER, MAKE SURE THE SYSTEM IS COMPLIANT WITH STANDARDS EN
12453
AND EN 12445 (REGARDING IMPACT FORCES), AND ALSO MAKE SURE
THE SYSTEM HAS BEEN PROPERLY ADJUSTED AND THAT ANY SAFETY, PROTECTION
AND MANUAL RELEASE DEVICES ARE WORKING PROPERLY • APPLY WARNING SIGNS
WHERE NECESSARY AND IN A VISIBLE PLACE (E.G. A PANEL ON THE BARRIER).
U
SER INSTRUCTIONS AND RECOMMENDATIONS
• KEEP BARRIER OPERATION AREAS CLEAN AND FREE OF ANY OBSTRUCTIONS.
M
AKE SURE THE OPERATING FIELD OF THE PHOTOCELLS IS CLEAR OF ANY OB-
STRUCTIONS • DO NOT ALLOW CHILDREN TO PLAY WITH FIXED COMMANDS, OR
TO LOITER IN THE BARRIER MANOEUVRING AREA. KEEP ANY REMOTE CONTROL
DEVICES (TRANSMITTERS) OR ANY OTHER COMMAND DEVICE OUT OF THE REACH OF
CHILDREN, TO PREVENT THE OPERATOR FROM BEING ACCIDENTALLY ACTIVATED •
T
HE APPARATUS MAY BE USED BY CHILDREN OF EIGHT YEARS AND ABOVE AND BY
PEOPLE WITH PHYSICAL OR COGNITIVE DISABILITIES, OR THOSE LACKING EXPERIENCE
OR RELEVANT KNOWLEDGE, PROVIDED THEY ARE CLOSELY SUPERVISED OR ONCE
THEY HAVE BEEN PROPERLY INSTRUCTED ON HOW TO USE THE APPARATUS SAFELY
AND ON THE POTENTIAL HAZARDS INVOLVED. CHILDREN MUST NOT PLAY WITH THE
APPARATUS. USER CLEANING AND MAINTENANCE MUST NOT BE PERFORMED BY UN-
SUPERVISED CHILDREN • FREQUENTLY CHECK THE SYSTEM FOR ANY MALFUNCTIONS
OR SIGNS OF WEAR AND TEAR OR DAMAGE TO THE MOVING STRUCTURES, OPERATOR
COMPONENTS, ANCHORING POINTS AND DEVICES, CABLES AND ACCESSIBLE CON-
NECTIONS. KEEP ANY JOINTS (HINGES) AND FRICTION POINTS (BOOM FLANGE) CLEAN
AND LUBRICATED • PERFORM FUNCTIONAL CHECKS ON THE PHOTOCELLS EVERY SIX
MONTHS. ALWAYS MAKE SURE THE PHOTOCELL GLASS COVERS ARE CLEAN (USE A
DAMP CLOTH; DO NOT USE SOLVENTS OR CHEMICALS THAT COULD DAMAGE THE
DEVICES) • IF REPAIRS OR MODIFICATIONS ARE REQUIRED TO THE SYSTEM, RELEASE
THE OPERATOR AND DO NOT USE IT UNTIL THE SAFETY CONDITIONS HAVE BEEN
RESTORED • CUT OFF THE ELECTRICAL POWER SUPPLY BEFORE RELEASING THE OP-
ERATOR FOR MANUAL OPENINGS. READ THE INSTRUCTIONS • IF THE POWER SUPPLY
CABLE IS DAMAGED, IT MUST BE REPLACED BY THE MANUFACTURER OR ITS AUTHOR-
ISED TECHNICAL ASSISTANCE SERVICE OR, IN ANY CASE, BY SIMILARLY QUALIFIED
PERSONS, TO PREVENT ANY RISK • USERS MUST NOT PERFORM ANY OPERATIONS
THAT ARE NOT EXPRESSLY REQUIRED OF THEM AND WHICH ARE NOT LISTED IN THE
MANUALS. FOR ANY REPAIRS, MODIFICATIONS, ADJUSTMENTS AND NON-SCHEDULED
MAINTENANCE, PLEASE CONTACT THE TECHNICAL ASSISTANCE SERVICE • LOG THE
WORK IN THE PERIODIC MAINTENANCE LOG.
A
DDITIONAL GENERAL RECOMMENDATIONS
• KEEP AWAY FROM AND DO NOT LOITER NEAR THE BARRIER BOOM OR MOVING
MECHANICAL PARTS • DO NOT ENTER THE AREA OF OPERATION WHEN THE BARRIER
IS MOVING • DO NOT COUNTER OR OBSTRUCT THE OPERATOR'S MOVEMENT AS
THIS COULD CAUSE DANGER • ALWAYS PAY SPECIAL ATTENTION TO ANY DANGEROUS
POINTS, WHICH MUST BE LABELLED WITH SPECIFIC PICTOGRAMS AND/OR BLACK
AND YELLOW STRIPES • WHEN USING A SELECTOR SWITCH OR A HOLD-TO-RUN
CONTROL, KEEP CHECKING THAT THERE ARE NO PERSONS WITHIN THE OPERATING
RANGE OF ANY MOVING PARTS, UNTIL THE CONTROL IS RELEASED • THE BARRIER
MAY MOVE AT ANY TIME AND WITHOUT WARNING • ALWAYS CUT OFF THE POWER
SUPPLY BEFORE PERFORMING ANY MAINTENANCE OR CLEANING.
