F5 Safety test 0 = Deactivated (default) / 1 = CX / 2 = CY / 3 = CX+CY
After every opening or closing command, the board will check whether the photocells are working properly.
F6 Hold-to-run 0 = Deactivated (default) / 1 = Activated
Press and hold a button to open and close the barrier. Opening button on [2-3]; closing button on contact [2-4]. With this function active, all
other command devices, including radio, are excluded.
F9 Obstruction detection function with motor idle 0 = Deactivated (default) / 1 = Activated
With the barrier open or closed or after a total stop, if the safety devices (photocells or safety edges) detect an obstacle the operator remains
stationary.
F10 Indicator light 0 = on with boom raised and moving (default) /
1 = fl ashes intermittently every half second during opening
fl ashes intermittently every second during closing
on with boom raised
o with boom lowered
It signals the barrier status. The light is connected to [10-5].
F11 Exclude encoder 0 = encoder activated (default) / 1 = encoder deactivated*
It manages slow-downs, obstruction detection and sensitivity.
* Connect the micro-switches to F-FC-FA.
F14 Sensor type selection 0 = control with transponder sensor or magnetic card reader
1 = control with keypad selector (default)
Setting the type of sensor to control the barrier.
F15 Luminous cord intermittence 0 = Boom moving (default) / 1 = Boom moving and closed
It signals the status of the barrier with intermittent lights.
F18 Additional light 0 = Flashing light (default) / 1 = Beacon / 2 = Courtesy light
Output on [10-E1].
The fl ashing light functions during opening and closing.
The beacon stays on from the moment the barrier begins to open until it is fully closed (including automatic closing time). Where the
automatic closing function is not activated, it only stays on during barrier movement.
The courtesy light either stays on for a fi xed period of 180 seconds or can be adjusted; see function F 25.
F19 Automatic closing time 0 = Deactivated (default) / 1 = 1 s / 2 = 2 s / … / 180 = 180 s
The waiting time before the barrier closes automatically starts when the limit-switch point is reached during opening. The time can be set
to between 1 s and 180 s. The barrier is not closed automatically where the safety devices are triggered by an obstacle, after a total stop or
where there is no power.
F21 Pre-fl ashing time 0 = Deactivated (default) / 1 = 1 s / … / 5 = 5 s
After an opening or closing command is given, the fl ashing light connected to 10-E1 fl ashes for between 1 s and 10 s before the barrier
begins to move.
F22 Working time 5 = 5 s / ...../ 120 = 120 s (default)
Gearmotor cycle time during opening or closing.
The working time can be set to between 5 s and 120 s
F25 Courtesy light time 5 = 5 s / ...../ 120 = 120 s (default).
Additional light; it stays on when the barrier opens and closes.
The time can be set to between 5 s and 120 s
F28 Opening manoeuvre speed 70 = Minimum speed / … / 100 = Maximum speed.
Setting the boom opening speed, calculated as a percentage.
⚠
Warning: the speed parameter fi elds vary according to the type of boom:
- for booms with a joint, between 2 m and 4 m, set the speed percentage from 70 to 100;
- for booms between 6 m and 8 m, set the speed percentage from 80 to 100.
F29 Closing manoeuvre speed 70 = Minimum speed / … / 100 = Maximum speed.
Setting the boom closing speed, calculated as a percentage.
⚠
Warning: the speed parameter fi elds vary according to the type of boom:
- for booms with a joint, between 2 m and 4 m, set the speed percentage from 70 to 100;
- for booms between 6 m and 8 m, set the speed percentage from 80 to 100.
