Canon Pixma iP2820 User Manual

Aligning the Print Head Position from Your Computer
Print head alignment corrects the installation positions of the print head and improves deviated colors and
lines.
The procedure for performing print head alignment is as follows:
Note
• If you are adjusting the head position while the software is being installed from the Setup CD-ROM,
start from Step 3.
Print Head Alignment
1.
Open the printer driver setup window
2.
Click Print Head Alignment on the Maintenance tab
The Start Print Head Alignment dialog box opens.
3.
Load paper in the printer
Load three sheets of A4 size or Letter size plain paper into the rear tray.
4.
Execute head alignment
Make sure that the printer is on and click Align Print Head.
Follow the instruction in the message.
5.
Check the printed pattern
Enter the numbers of the patterns with the least amount of streaks in the associated boxes.
Even if the patterns with the least amount of streaks are clicked in the preview window, their numbers
are automatically entered in the associated boxes.
71

Canon Pixma iP2820 Specifications

General

Color	Yes
Maximum duty cycle	- pages per month
Number of print cartridges	-
Maximum resolution	4800 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	8 ppm
Print speed (color, normal quality, A4/US Letter)	4 ppm
Total input capacity	- sheets
Auto document feeder (ADF) input capacity	60 sheets
Paper tray media types	Envelopes, Glossy paper, Plain paper
Photo paper sizes (imperial)	4x6, 5x7 \
Maximum ISO A-series paper size	A4
Ethernet LAN	No
Standard interfaces	USB 2.0
Power consumption (printing)	- W
Product color	White
Market positioning	Home & office

Weight and Dimensions

Depth	236.22 mm
Width	426.72 mm
Height	134.62 mm
