Canon PIXMA TR4520 User Manual

Setting a Page Size and Orientation
The paper size and orientation are essentially determined by the application software. When the page size
and orientation set for Page Size and Orientation on the Page Setup tab are same as those set with the
application software, you do not need to select them on the Page Setup tab.
When you are not able to specify them with the application software, the procedure for selecting a page size
and orientation is as follows:
You can also set page size and orientation on the Quick Setup tab.
1.
Open the printer driver setup window
2.
Select the paper size
Select a page size from the Page Size list on the Page Setup tab.
3.
Set Orientation
Select Portrait or Landscape for Orientation. Check Rotate 180 degrees check box when you want to
perform printing with the original being rotated 180 degrees.
4. Click OK
When you execute print, the document will be printed with the selected page size and the orientation.
Note
• If Normal-size is selected for Page Layout, then Automatically reduce large document that the
printer cannot output is displayed.
Normally, you can leave the check box checked. During printing, if you do not want to reduce large
documents that cannot be printed on the printer, uncheck the check box.
234

Canon PIXMA TR4520 Specifications

General

Print Technology	Inkjet
Print Resolution	Up to 4800 x 1200 dpi
Automatic Document Feeder	Yes
Duplex Printing	Yes
Operating System Support	Windows, Mac OS
Functions	Print, Copy, Scan, Fax
Paper Capacity (Plain Paper)	100 sheets
Scan Resolution (Max)	1200 x 2400 dpi
Connectivity	Wi-Fi, USB
Supported Paper Sizes	4" x 6", 5" x 7", 8" x 10", Letter, Legal
Print Speed (Black)	8.8 ipm (Black)
Print Speed (Color)	4.4 ipm (Color)
Scanner Type	Flatbed, ADF
Copier Speed (Color)	2.7 ipm (Color)
Fax Speed (Black)	Approx. 3 seconds per page
Dimensions (W x D x H)	17.2" x 11.7" x 7.5"
Fax Speed (Color)	Approx. 1 min per page
Weight	Approx. 13 lbs
