Canon PIXMA TR4520 User Manual

Setting Items for Sending Faxes
If you select FAX TX settings after pressing the Menu/Wireless connect button on the Fax standby
screen, you can specify the settings of the scan contrast and the scan resolution.
Adjust the scan contrast and resolution following the procedure below.
1.
Press the Menu/Wireless connect button on the Fax standby screen.
The FAX menu screen is displayed.
2.
Select FAX TX settings, then press the OK button.
3.
Select Scan contrast, then press the OK button.
4.
Select the scan contrast, then press the OK button.
The button decreases the scan contrast, and the button increases the scan contrast.
5.
Select Scan resolution, then press the OK button.
6.
Select the scan resolution.
Note
• The (asterisk) on the LCD indicates the current setting.
Standard
Suitable for text-only documents.
Fine
Suitable for fine-print documents.
Extra fine
Suitable for detailed illustration or fine-print quality documents.
If the recipient's fax device is not compatible with Extra fine (300 x 300 dpi), the fax will be sent in
the Standard or Fine resolution.
Suitable for photographs.
403

Canon PIXMA TR4520 Specifications

General

Print Technology	Inkjet
Print Resolution	Up to 4800 x 1200 dpi
Automatic Document Feeder	Yes
Duplex Printing	Yes
Operating System Support	Windows, Mac OS
Functions	Print, Copy, Scan, Fax
Paper Capacity (Plain Paper)	100 sheets
Scan Resolution (Max)	1200 x 2400 dpi
Connectivity	Wi-Fi, USB
Supported Paper Sizes	4" x 6", 5" x 7", 8" x 10", Letter, Legal
Print Speed (Black)	8.8 ipm (Black)
Print Speed (Color)	4.4 ipm (Color)
Scanner Type	Flatbed, ADF
Copier Speed (Color)	2.7 ipm (Color)
Fax Speed (Black)	Approx. 3 seconds per page
Dimensions (W x D x H)	17.2" x 11.7" x 7.5"
Fax Speed (Color)	Approx. 1 min per page
Weight	Approx. 13 lbs
