Canon IJ Network Device Setup Utility Screen
Items on Canon IJ Network Device Setup Utility Screen
Menus on Canon IJ Network Device Setup Utility Screen
Items on Canon IJ Network Device Setup Utility Screen Toolbar
Items on Canon IJ Network Device Setup Utility Screen
The screen below appears when you start up IJ Network Device Setup Utility and select Printer Network
Setup. Detected printers are listed on the screen and the items below are shown.
A: Product Name
Displays the product name of detected printer. The icon below appears on the left if the printer cannot
be used.
: Appears when the printer requires setup or has not been configured.
: Appears when the IP address is duplicated to another printer.
: Appears when you cannot communicate with the printer.
Note
• If a printer you want to use is not detected, try to set the criteria for printer search.
Setting Criteria for Printer Search/Searching Specific Printer
• Right-clicking a printer displays setting items or items to confirm.
B: Serial Number (Last 5 Digits)
Displays the last five digits of printer's serial number.
C: Status
Displays the printer status as shown below.
• Available
Indicates the printer is available.
• Setup Completed
65

Canon PIXMA TR4520 Specifications

General

Print Technology	Inkjet
Print Resolution	Up to 4800 x 1200 dpi
Automatic Document Feeder	Yes
Duplex Printing	Yes
Operating System Support	Windows, Mac OS
Functions	Print, Copy, Scan, Fax
Paper Capacity (Plain Paper)	100 sheets
Scan Resolution (Max)	1200 x 2400 dpi
Connectivity	Wi-Fi, USB
Supported Paper Sizes	4" x 6", 5" x 7", 8" x 10", Letter, Legal
Print Speed (Black)	8.8 ipm (Black)
Print Speed (Color)	4.4 ipm (Color)
Scanner Type	Flatbed, ADF
Copier Speed (Color)	2.7 ipm (Color)
Fax Speed (Black)	Approx. 3 seconds per page
Dimensions (W x D x H)	17.2" x 11.7" x 7.5"
Fax Speed (Color)	Approx. 1 min per page
Weight	Approx. 13 lbs
