Canon PowerShot A560 User Manual

106
If the Date/Time menu appears when the camera power is turned
on, the date battery charge is low and the date and time settings
have been lost. Please purchase a lithium coin battery (CR1220)
and replace it as follows.
Replacing the Date Battery
The date battery is preinstalled at the factory and may therefore
expire earlier than its rated lifespan after the camera has been
purchased.
Be particularly careful to keep the date batteries out of the
reach of children. Seek medical assistance immediately if a
child swallows a battery since corrosive battery fluids could
damage the stomach or intestinal wall.
1
Confirm that the camera is turned off.
2
Slide the memory card slot/battery cover
lock and open the cover.
3
Hook your nail onto the date battery holder
(a) and lightly pull it up in the direction
indicated by the arrow (b).
4
Remove the battery by
pulling it up in the
direction indicated by
the arrow.
(–) Side

Canon PowerShot A560 Specifications

General

Megapixel	7.1 MP
Sensor type	CCD
Image sensor size	1/2.5 \
Still image resolution(s)	640 x 480, 1600 x 1200, 1600 x 1200, 2048 x 1536, 2592 x 1944, 3072 x 1728, 3072 x 2304
Digital zoom	4 x
Interface	USB
Digital SLR	No
Video capability	Yes
Camera shutter speed	15 – 1/2000 s
Compatible operating systems	Windows 2000 SP4/XP/Vista; Mac OS X v10.3 - 10.4
Focus	TTL
ISO sensitivity	80, 100, 200, 400, 800, 1600, AUTO
Internal memory	16 MB
Compatible memory cards	mmc, sd
Display diagonal	2.5 \
I/O ports	USB; A/V out (PAL/NTSC)
Product color	Silver
Battery type	AA Alkaline/ NiMH (NB4-300)
Number of batteries supported	2
Operating temperature (T-T)	0 - 40 °C
Flash modes	auto, manual, Red-eye reduction
Viewfinder type	Optical

Weight and Dimensions

Depth	43.1 mm
Width	91.2 mm
Height	64 mm
Weight	165 g
