Canon PowerShot A560 User Manual

16
The viewfinder (Basic Guide p. 2) can be used to conserve power
by turning the LCD monitor off (p. 12) while shooting.
Histogram Function
The histogram is a graph that allows you to check the brightness
of the image. The greater the bias toward the left in the graph, the
darker the image. The greater the bias toward the right, the
brighter the image.
If the image is too dark, adjust the exposure compensation to a
positive value. Similarly, adjust the exposure compensation to a
negative value if the image is too bright (p. 46).
Using the Viewfinder
Sample Histograms
Balanced ImageDark Image Bright Image
Shows the center of the image
Viewfinder

Canon PowerShot A560 Specifications

General

Megapixel	7.1 MP
Sensor type	CCD
Image sensor size	1/2.5 \
Still image resolution(s)	640 x 480, 1600 x 1200, 1600 x 1200, 2048 x 1536, 2592 x 1944, 3072 x 1728, 3072 x 2304
Digital zoom	4 x
Interface	USB
Digital SLR	No
Video capability	Yes
Camera shutter speed	15 – 1/2000 s
Compatible operating systems	Windows 2000 SP4/XP/Vista; Mac OS X v10.3 - 10.4
Focus	TTL
ISO sensitivity	80, 100, 200, 400, 800, 1600, AUTO
Internal memory	16 MB
Compatible memory cards	mmc, sd
Display diagonal	2.5 \
I/O ports	USB; A/V out (PAL/NTSC)
Product color	Silver
Battery type	AA Alkaline/ NiMH (NB4-300)
Number of batteries supported	2
Operating temperature (T-T)	0 - 40 °C
Flash modes	auto, manual, Red-eye reduction
Viewfinder type	Optical

Weight and Dimensions

Depth	43.1 mm
Width	91.2 mm
Height	64 mm
Weight	165 g
